TEW-423PI 54Mbps Wireless PCI Card cuts the wires to your desktop and provides 54Mbps speed to handle bandwidth-intensive applications. It complies with the IEEE 802.11g standard, making it backward compatible with 802.11b networks for assured compatibility. Advanced 128-bit WEP encryption is supported to provide secure access for your data. Cut the wires and move your desktop where you need it with TRENDnet’s 802.11g wireless PCI Card.
Features
Wi-Fi Compliant with IEEE 802.11g and IEEE 802.11b Standards
Uses 2.4 GHz Frequency Band, which Complies with Worldwide Requirements
Supports Ad-Hoc (Peer-to-Peer) Mode or Infrastructure (AP-Client) Mode
Dynamic Data Rate Scaling at 54, 48, 36, 24, 18, 12, 9 and 6Mbps for 802.11g
Dynamic Data Rate Scaling at 11, 5.5, 2 and 1Mbps for 802.11b
Maximum Reliability, Throughput and Connectivity with Automatic Data Rate Switching
Compatible with Windows 7/Vista/XP/2000/ME/98SE
Supports 64/128-bit WEP, WPA/WPA2 and WPA-PSK/WPA2-PSK
Detachable 2dBi dipole Antenna with Reverse SMA Connector
Low Interference and High Susceptibility Guarantee Reliable Performance
Range of 35~100 meters indoor, 100~300 meters outdoor (depends on the environment)
Simple User Setup & Diagnostics Utilities
3-year limited warranty
Specifications
Hardware
Interface
32-bit PCI 2.2 Bus Master
Standards
IEEE 802.11b and IEEE 802.11g
Antenna
1 x 2dBi Detachable Dipole Antenna
LED Indicator
Link
Power Consumption
Receive Mode: 370mA Transmit Mode: 470 mA
Supported OS
Windows 7 (32/64-bit), Vista (32/64-bit), XP (32/64-bit), 2000, 98SE
Dimensions
121 x 44 mm (4.8 x 1.7 inches) (without metal bracket)
Weight
60g (2.1oz.) (with antenna)
Temperature
Operating: 0° ~ 40° C (32° ~ 104° F) Storage: -10° ~ 70° C (14° ~ 158° F)
