N150 Wireless Home Router
TEW-651BR (Version v1.0R)
  • 6x the speed and 3x the coverage of wireless g
  • Seamlessly stream video, download files, talk online and play games
  • Advanced wireless encryption protects your valuable data
  • Intuitive installation process


 DISCONTINUED PRODUCT
The TEW-651BR (Version v1.0R) has been discontinued.  It has been replaced by the TEW-651BR (Version v2.0R). For a list of discontinued products, click here.

The N150 Wireless Home Router delivers the highest level of security with 6x the speed and 3x the coverage of wireless g products. Quickly install the router and use it with TRENDnet wireless n adapters to receive the full benefits of wireless n speed and coverage.

The latest in wireless encryption and a secure firewall protect your valuable data. Router setup is fast and intuitive. Wireless Protected Setup (WPS) integrates other WPS supported wireless adapters at the touch of a button. Seamlessly stream HD media, download files and surf online with wireless n speed.

*Maximum wireless signal rates are referenced from IEEE 802.11 theoretical specifications. Actual data throughput and coverage will vary depending on interference, network traffic, building materials and other conditions.



RoHS Compliant
  • Based on IEEE 802.11n technology and compliant with IEEE 802.11b/g standards
  • 4 x 10/100Mbps Auto-MDIX LAN ports
  • 1 x 10/100Mbps WAN port (Internet)
  • GREENnet technology reduces port-based power consumption
  • Compatible with most popular cable/DSL Internet service providers using Dynamic/Static IP, PPPoE, PPTP and L2TP
  • High-speed data rates of up to 150Mbps with IEEE 802.11n*
  • Wi-Fi Protected Setup (WPS) connects wireless clients at the push of a button
  • Supports 64/128-bit WEP, WPA/WPA2-RADIUS and WPA-PSK/WPA2-PSK
  • Internet Access Control (MAC Address, Domain and IP Filtering)
  • Ea­­sy remote management via Web browser
  • Firewall features Network Address Translation (NAT)
  • Universal Plug and Play (UPnP) and Application Level Gateway support for Internet applications such as email, FTP, gaming, remote desktop, Net Meeting, Telnet and more
  • Wi-Fi Multimedia (WMM) Quality of Service (QoS) supported
  • Simple setup via Web browser using the latest version of Internet Explorer, Firefox, and Safari
  • Works with Windows, Linux, and Mac operating systems
  • Indoor range up to 100 meters (330 ft.) depending on the environment
  • Outdoor range up to 300 meters (980 ft.) depending on the environment
  • 3-year limited warranty

*Maximum wireless signal rates are referenced from IEEE 802.11 theoretical specifications. Actual data throughput and coverage will vary depending on interference, network traffic, building materials and other conditions.

  • Hardware
  • Standards
  • IEEE 802.3 (10Base-T) IEEE 802.3u (100Base-TX) IEEE 802.11b IEEE 802.11g Based on IEEE 802.11n technology
  • WAN
  • 1 x 10/100Mbps Auto-MDIX WAN port (Internet)
  • LAN
  • 4 x 10/100Mbps Auto-MDIX LAN port
  • WPS Button
  • Enables Wi-Fi Protected Setup (WPS) function
  • Connection Type
  • Dynamic IP, Static (fixed) IP, PPPoE, PPTP, L2TP
  • Supported Web Browsers
  • Internet Explorer 6.0 or above, Firefox, Safari
  • Internet Access Control
  • MAC Address Filter (20 entries), Domain/URL Filter (40 entries), Protocol/IP Filter (20 entries)
  • LED Indicators
  • Power, Status, LAN1 - LAN4, WAN, WLAN
  • Power Supply
  • 5V DC, 1.2A external power adapter
  • Power Consumption
  • 3.5 watts (max)
  • Dimensions (LxWxH)
  • 150 x 110 x 30mm (5.9 x 4.3 x 1.2in)
  • Weight
  • 225g (7.8oz)
  • Temperature
  • Operating: 0° ~ 40°C (32° ~ 104°F) Storage: -10°C ~ 70°C (-14° ~ 158°F)
  • Humidity
  • 10% ~ 95% max (non-condensing)
  • Certifications
  • CE, FCC
  • Wireless
  • Frequency
  • 2.412 ~ 2.484 GHz ISM band
  • Antenna
  • 1 x 2dBi fixed dipole antenna
  • Module Technique
  • 802.11b: CCK (11 and 5.5Mbps), DQPSK (2Mbps), DBPSK (1Mbps) 802.11g: OFDM with BPSK, QPSK and 16/64-QAM 802.11n: BPSK, QPSK, 16QAM, 64QAM with OFDM
  • Media Access Protocol
  • CSMA/CA with ACK
  • Data Rate (Auto Fallback)
  • 802.11b: up to 11Mbps 802.11g: up to 54Mbps 802.11n: up to 150Mbps
  • Output Power
  • 802.11b: 15dBm (typical) @ 11Mbps 802.11g: 15dBm (typical) @ 54Mbps 802.11n: 13dBm (typical) @ 150Mbps
  • Receiving Sensitivity
  • 802.11b: -85dBm (typical) @ 11Mbps 802.11g: -68dBm (typical) @ 54Mbps 802.11n: -62dBm (typical) @ 150Mbps
  • Encryption
  • 64/128-WEP, WPA-PSK/WPA2-PSK, WPA/WPA2-RADIUS
  • Channels
  • 1-11 (FCC), 1-13 (ETSI)
  •

    Package Contents

    • TEW-651BR
    • Multi-Language Quick Installation Guide
    • CD-ROM (User’s Guide)
    • Cat. 5 Ethernet cable (1.5m / 4.9ft)
    • Power adapter (5V DC, 1.2A)
