8-Port 100base-FX Layer 2 Managed Fiber Switch w/ Mini-GBIC Port
TEG-S081FMi (Version 1.0R)

Expand your fiber network with this high-performance switch
8 x 100Base-FX (SC) Multi-Mode fiber ports and 1 x Gigabit Mini-GBIC slot
Supports SNMP, Telnet, IGMP and layer 2 features such as Port Trunking, Mirroring and VLAN
3.8Gbps switching capacity

Click on image to enlarge

The 8-Port 100Base-FX Layer 2 Managed Switch provides exceptional performance, ease of use and flexibility for expanding network operations. Utilizing a robust 3.8Gbps backplane, the switch can easily accommodate multiple networks at 2km or more with an optional GBIC SX or LX module. Advanced management features include SNMP, VLAN, IGMP, and Port Security.

8 x 100Base-FX SC type multi-mode fiber port
1 x 1000Base mini GBIC Slot for optional mini GBIC module
Supports switch fabric up to 3.6GBps
Layer 2 management switch with full software support
IGMP snooping with query mode support for multi-media application
Supports broadcast storm filtering
Supports Port status control (status, auto-negotiation, speed, duplex and flow control)
Supports port trunking with flexible load distribution control and fail-over functions
Supports port-based VLAN and IEEE 802.1Q tag-based VLAN
Supports IP multicast, port mirroring, spanning tree, SNMP and RMON
Supports port security and IEEE 802.1p class of services
Store-and-forward switching Architecture with non-blocking wire-speed performance
Configuration via RS-232 console port, telnet, and web browser (HTTP)
TFTP firmware upgrade via browser
Configuration save and restore feature support
19” (1U) Rack mount design (kit included)
3-year limited warranty

Hardware
Standards	IEEE 802.3u 100Base-FX IEEE 802.3z Gigabit Fiber/IEEE 802.3ab 1000Base-T IEEE 802.3x Flow Control IEEE 802.1D Spanning Tree IEEE 802.1q Tag-based VLAN IEEE 802.1p Class of Service Link Aggregation IEEE 802.1ad Port Trunk
Interface	8 x 100Base-FX SC type Multi-Mode Fiber Port 1 x 1000Base mini GBIC slot for optional mini GBIC module (3.3V DC power)
Packet Forwarding and Filtering Rate	Gigabit: 1,488,000 packets per second per port 100M Ethernet: 148,800 packets per second per port
Cabling	Multi-Mode: (50/125um, 62.5/125um), 2km max Single-Mode: (8/125um, 10/125um)
Console Port	RS-232, female 9-Pin Serial Port (M-M serial cable included)
Protocol/Topology	(CSMA/CD) / Star
Buffer Memory	2Mbits Data Buffer
Filtering Address Table	8K MAC Address Entries
Switching Fabric	Up to 3.6Gbps
LED Display	Power, Link/Activity, Full Duplex/Collision
Power	Input: 100~240VAC, 50/60Hz Internal Power Supply
Power Consumption	17 watts
Dimensions	440 x 160 x 44mm (17.3 x 6.3 x 1.7 inch) (W x H x D)
Weight	2.2 Kg. (4.85lb.)
Temperature	Operating: 0° ~ 45° C (32° ~ 113° F) Storage: -40° ~ 70° C (-40° ~ 158° F)
Humidity	10% ~ 90% non-condensing
Certifications	FCC, CE
Software
Management	Web Management, RS-232 Console Management, Telnet
Trunk	IEEE 802.3ad Trunk with LACP. Max 4 Groups ( up to 4 Ports per group)
Class of Service	Supports Hi and Low Priority
QoS	Supports 8 Levels of Priority and Mapping to Hi/Low Priority Queue for Class of Service
VLAN	Up to 256 VLAN groups and up to 4094 VLAN ID
IP Multicast	IGMP Snooping up to 256 groups 2 Types of Query Mode: Enable/Disable or Auto Query
Filter Database	Port Static MAC address lock, MAC filter and Port Security
Port Mirror	Up to 8 ports
Broadcast Control	None, 5%, 10%, 15%, 20%, 25%
Spanning Tree	IEEE 802.1d Support
RFC Standard	RFC 1157 SNMP v1.0, RFC 1213 MIB II, Bridge MIB, RFC 1643 Ethernet Like, RFC 1493 Bridge MIB, RFC 1757 RMON1, RFC 1215 Trap

Information provided in this document pertain to TRENDnet products and is subject to change at any time, without notice.

Additional Info

Email a Friend

Datasheet

Quick Installation Guide

Downloads

Package Contents

TEG-S081FMi
Multi-language user´s guide
Power cord
RS-232 cable
