1-Port Parallel Print Server
TE100-P1P (Version 2.xR)

Turns a standalone parallel printer into a shared network resource
Manages print server through web browser or utility

DISCONTINUED PRODUCT

The TE100-P1P (Version 2.xR) has been discontinued. It has been replaced by the TE100-P1P (Version v3.0R). For a list of discontinued products, click here.

Click on image to enlarge

The 10/100Mbps Parallel Print Server is designed to transform virtually any conventional stand-alone networkable parallel port printer into a shared resource on your network. Compact in design, but packed with features the TE100-P1P is the most cost effective way to add a parallel printer anywhere on your network!

Compliant with Bi-Directional 36-pin parallel port
One RJ-45 10/100Mbps Auto-MDIX Fast Ethernet port
Supports LPR printing for Windows
Supports IPP printing for Windows 7/Vista/XP/2000
Web-based (HTTP) configuration
Supports second HTTP port for remote Web configuration
Supports Macintosh Rendezvous Zero Configuration*
Windows-based setup wizard and configuration utility
Built-in flash memory for easy firmware upgrade
3-years limited warranty

*Mac Systems are only compatible with Post-Script printers

HARDWARE
Standards	IEEE 802.3 10Base-T IEEE 802.3u 100Base-TX
Printer Interface	IEEE 1284 Male Centronics (DB-36)
LAN Port	10/100Mbps MDIX Ethernet Port
LED	Power, LPT, Link/Act
Transport Protocol	TCP/IP, SMB
OS Support	Windows 7(32/64-bit)/Vista(32/64-bit)/2003 Server/XP(32/64-bit)/2000/ME/98SE Netware 5.x NDPS LPR Remote Printing (TCP/IP) Unixware, Linux Mac OS X 10.1~10.6
Management	PS Utility or Web-Browser Configuration
Power	5V DC 2.5A External Power Adapter
Dimension (L x W x H)	57 x 90 x 32mm (2.2 x 3.5 x 1.3 inches)
Weight	74 g (2.6 oz.)
Temperature	Operating: 5°~40°C (41°~104°F) Storage: -25°~50°C (-13°~122°F)
Humidity	5%~95% (non-condensing)
Certifications	CE, FCC

Information provided in this document pertain to TRENDnet products and is subject to change at any time, without notice.

Additional Info

Email a Friend

Datasheet

Quick Installation Guide

Downloads

View Knowledgebase

Package Contents

TE100-P1P
Multi-Language Quick Installation Guide
CD-ROM (Utility & User’s Guide)
Power Adapter (5V DC, 2.5A)
