32/64-bit 1000Base-SX Gigabit Ethernet Adapter
TEG-PCISXplus

This full-duplex gigabit adapter brings high bandwidth with 1000Mbps speed, which makes more bandwidth available for the applications.
Enjoy a 32-bit PCI bus as well as 64-bit PCI bus, making it the perfect choice for greater bandwidth and the cost effective solution for high-speed network connectivity
Enjoy a 5-year warranty

DISCONTINUED PRODUCT

The TEG-PCISXplus has been discontinued. For a list of discontinued products, click here.

Click on image to enlarge

TRENDnet's TEG-PCISXplus 32/64-bit Gigabit Ethernet Fiber Adapter is built to increase system performance by high-level functions. This full-duplex Gigabit adapter brings high data transfer rate with 2000Mbps speeds, delivering more bandwidth for your network applications. TRENDnet's TEG-PCISXplus provides the benefit of Gigabit Ethernet networking with the familiarity of Ethernet that operates in existing 32-bit PCI bus, as well as 64-bit PCI bus, making it the perfect choice for greater bandwidth and cost effective solution for high-speed network connectivity.

IEEE 802.3z 1000Base-SX compliant
Support 32/64-Bit PCI Local Bus Master high-speed operation of rev. 2.1/2.2 specification
Plug and Play Installation
SC Type connector for 62.5/125µm or 50/125 µm multi-mode fiber optic cable
Supports Full-Duplex mode doubles network Data rate to 2000Mbps
Supports IEEE 802.1q VLAN and IEEE 802.1p QoS
Built-in 32KB FIFO buffer memory reduces overhead of memory transfer
5-year limited warranty


Hardware
Standards:	IEEE 802.3z 1000Base-SX Gigabit Ethernet
Protocol:	CSMA/CD
Network Media:	62.5/125um multi-mode fiber optic cable with SC type connector, 220 meters max. 50/125um multi-mode fiber optic cable with SC type connector, 550 meters max.
Host Interface:	32/64-Bit PCI rev. 2.1/2.2
Supported Drivers:	Microsoft Windows 98/Me/2000/NT4.0/XP, Novell Netware Server 5.x, Linux 2.2, 2.4
Diagnostic LEDs:	Link, Activity
Network Data Transfer:	2000Mbps Full-Duplex
Dimensions:	175 x 69 mm (6.9 x 2.7 inches)
Weight:	Approximately 120 g. (4.25 Oz.)
Temperature:	Operating: 0° ~ 65° C (32° ~ 149° F) Storage: -10° ~ 70° C (14° ~ 158° F)
Humidity:	10% - 90% (non-condensing)
Certifications:	FCC Class B, CE Mark B, VCCI-B

Information provided in this document pertain to TRENDnet products and is subject to change at any time, without notice.
