26-port 10/100/1000Mbps Gigabit Web-Based Smart Switch
TEG-224WS

DISCONTINUED PRODUCT

The TEG-224WS has been discontinued. It has been replaced by the TEG-224WSplus (Version A1.0R). For a list of discontinued products, click here.

Click on image to enlarge

TRENDnet's TEG-224WS 26-port 10/100/1000Mbps Web-Based Smart Switch is the ideal Switch for network segmenting and flexibility. It has 24 10/100Mbps and 2 10/100/1000Mbps Auto-Sensing and Auto-MDIX ports. TEG-224WS supports web browser configuration allowing Network Administrators to configure speed, VLAN, QoS, Trunking and Mirroring down to the port level. TRENDnet's TEG-224WS is powerful, easy-to-use and enhances network security.

24 x 10/100Mbps Auto-negotiation MDIX Fast Ethernet Ports
2 x 10/100/1000Mbps Auto-negotiation, Auto-MDIX Gigabit Ports
Full/Half duplex transfer mode for each port (full duplex mode only for Gigabit)
Store and Forward switching method
Integrated address Look-Up Engine with 6K absolute MAC address table
Supports 4MB RAM Data Buffering
Extensive diagnostic LED’s on the front panel
IEEE 802.3x flow control for Full Duplex mode
Back pressure flow control for Half Duplex mode
Easy configuration the device from a Web browser
Supports Port-Based VLAN and Port-Based IEEE 802.1p QoS
Supports Trunking (gigabit ports) and Port Mirroring
Support Port setting function allow user setting each port’s speed, duplex mode, and flow control
Standard 19” Rack-mount design
5-year limited warranty


Hardware
LAN Standards:	IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3ab 1000Base-T, IEEE 802.3x Full Duplex Flow Control
Network Media:	Ethernet: UTP/STP Cat. 3, 4, 5 Fast Ethernet: UTP/STP Cat. 5 Gigabit : UTP/STP Cat. 5, Cat 5E (Recommend)
Protocol:	CSMA/CD
Topology:	Star
LAN Port:	24 x 10/100Mbps Auto Negotiation, Auto-MDIX Fast Ethernet ports, 2 x 10/100/1000Mbps Auto Negotiation, Auto MDIX Gigabit ports Address Table: 6K entries per device
Data RAM buffer:	4MB per device
Data Transfer Rate:	Ethernet: 10/20Mbps – Half/Full-Duplex Fast Ethernet: 100/200Mbps – Half/Full Duplex Gigabit Ethernet: 2000Mbps – Half/Full Duplex
Diagnostic LEDs:	Per Unit: Power, System Per Fast Ethernet Port: Link/ACT, 100M (port 1~24) Per Gigabit Ethernet Port: Link/ACT, 1000M, 100M (port 25,26)
Power Consumption:	16 Watts. Max
	Power Supply:100-240V AC, 50/60Hz Internal Universal Power Supply
Dimensions:	440 x 140 x 44 mm (17.32" x 5.5" x 1.73")
Weight:	4.7 lb
Temperature:	Operating: 0° ~ 40° C (32° ~ 104° F) Storage: -10° ~ 70° C (14° ~ 158° F)
Humidity:	10% ~ 90% (no-condensing)
Certifications:	FCC Class A, CE Mark A, VCCI-A

Information provided in this document pertain to TRENDnet products and is subject to change at any time, without notice.
