Product Families » Wireless Networking » Wireless Antennas » Outdoor Antennas » TEW-AO10O
10dBi Outdoor Omni Directional Antenna
TEW-AO10O
  • Create a high powered blanket outdoor Wi-Fi hotspot
  • Compatible with wireless b, g and n standards
  • Ensure protection from lightning strikes with TRENDnetīs TEW-ASAK Outdoor Arrestor Kit
  • Includes mounting kit


TEW-AO10O
Click on image to enlarge

The 10dBi Outdoor Omni Directional Antenna expands wireless coverage for existing 802.11b/802.11g wireless networks to improve wireless performance at longer distances. Perfect for Wi-Fi hotspots and wireless home networks, the antenna blankets any given area with Wi-Fi signals to provide continuous connectivity in every direction. In outdoor applications, the TEW-AO10O can withstand winds of up to134mph as well as multiple lightning strikes with the addition of the TEW-ASAK Outdoor Arrestor Kit.

* This dBi gain does not factor cable loss. Performance estimations are for typical use; range will vary with site conditions.


RoHS Compliant

  • Compatible with 2.4GHz 802.11b/g wireless products.
  • Boosts and increases the effective range coverage by 8X the area covered by the base station alone.
  • Easy-to-install wall / pole mounting.
  • No configuration or installation software required.
  • 3-year limited warranty.
Hardware
Frequency Range 2400-2500MHz
Gain 10dBi
VSWR 2.0:1
Polarization Linear, vertical
HPBW/ Horizontal 360°
HPBW/ Vertical 10°
Power Handling 10W (cw)
Down Tilt
Impedance 50 Ohms
Connector N-Type Female
Survival Wind Speed 216 Km/ h (134miles/h)
Lightning Protection DC ground
Radome Color Gray white
Radome Material Fiberglass
Dimension 25 x 80 x 880mm (0.98 x 3.15 x 34.65in.)
Weight 408g (14.4oz.)
Temperature -40°C ~ 80°C (-40°F ~ 176°F)
Humidity 100% at 25°C (77°F)
Certification CE, FCC
Warranty 3 Years
* Note: For optimal results in extending your wireless range with wireless antenna installations, we recommended that you consult a professional installer for site survey, safety precautions, and proper installation.
Pattern


TEW-AO10O

Information provided in this document pertain to TRENDnet products and is subject to change at any time, without notice.
Additional Info
Email a Friend
Datasheet
Quick Installation Guide
Downloads
Register Your Product
Package Contents
  • TEW-AO10O
  • Userīs Guide
  • Mounting Kit
