10/100Mbps PCMCIA Ethernet Cards
TE100-PC16 (Version 1.0)

DISCONTINUED PRODUCT

The TE100-PC16 (Version 1.0) has been discontinued. It has been replaced by the TE100-PC16R (Version 1.0). For a list of discontinued products, click here.

Click on image to enlarge

The perfect solution for connecting to today’s high-speed LAN through your laptop computer is TRENDnet’s TE100-PC16 Fast Ethernet Card. TRENDnet’s TE100-PC16 supports full duplex mode making data rates up to 200Mbps. Plug and Play compatible, the TE100-PC16 provides easy installation that is done minutes. And the TE100-PC16 is fully compatible with your existing 10Mbps Ethernet.

PCMCIA 2.1/JEIDA 4.1 compliant
10Mbps or 100Mbps data rates auto-negotiation
Feature full duplex mode that doubles the network connection speed
Diagnostics LED indicators: LINK, ACT, and 10/100Mpbs
Media coupler support both Category 3/5 (100Base-T) and CAT 5 (100Base-TX)
Support all major Network Operating Systems (NOS)
Menu-driven installations utility and LAN diagnostics program included
PC Card hot swap supported
Ultra low power consumption
Innovative power-down mode support
Compatible with extensive notebook models
5-year limited warranty


Hardware
Standards:	IEEE 802.3 for 10Base-T, and IEEE 802.3m for 100Base-TX, PCMCIA CardBus PC Card Standard (TE100-PCBus)
Cabling:	CAT 3, 4, 5 UTP/STP for 10Base-T, CAT 5 for 100Base-TX
LED’S:	ACT, Link, 10/100 Mbps
Card and Socket Service Support:	PC Card Standard, Windows NT 4.X direct enabler, DOS/Windows 3.1 direct enabler
Network Driver’s:	Windows XP, Windows NT 3.5x & 4.x, Windows 3.1 (DOS) Windows 95/98, & OSR2, Windows for Workgroups, Novell Netware 3.x & 4.x Client. Personal Netware, Netware Microsoft LAN Manager, Artisoft LANtastic, IBM LAN Support, DEC Pathworks, FTP, PC/TCP. Packet Driver
Temperature:	Operating: 32° to 140° F (0° to 60°C) Storage: 4° to 158° F (-15.5° C to 70° C)
Humidity:	10% to 95% non-condensing
Power Consumption:	Operation: +3.3V, 300mA (Max.) Power-Down: +3.3V, 80mA
Certification:	FCC, UL, CE

Information provided in this document pertain to TRENDnet products and is subject to change at any time, without notice.
