26-Port 10/100/1000Mbps NWay Copper Gigabit Ethernet Switch
TEG-S224TX

DISCONTINUED PRODUCT

The TEG-S224TX has been discontinued. It has been replaced by the TEG-S224TXA . For a list of discontinued products, click here.

Click on image to enlarge

TRENDnet’s TEG-S224TX is a 26-port 10/100/1000Mbps NWay Gigabit Switch with 24 10/100Mbps NWay Ethernet ports and two 1000Base-T Copper Gigabit Ethernet ports. All ports supports full and half duplex transfer mode with non-blocking store-and-forward switching method. This high-performance switch also supports IEEE 802.1p Quality of Service (QoS) for priority data packet processing. And with Broadcast Storm Control, Port Trunking, and VLAN supports, the TEG-S224TX is powerful and easy-to-use in reducing unnecessary broadcast traffic, segmenting the network, and enhancing network security.

2 10/100/1000Mbps Auto-Negotiation Copper Gigabit Ethernet Ports
24 10/100Mbps Auto-Negotiation Ethernet/Fast Ethernet Ports
Full/half Duplex transfer mode for each 10/100/1000Mbps ports
Auto MDI-II / MDI-X media type detection for all ports
Supports store and forward architecture with non-blocking full wire speed performance
802.3x flow control for full duplex and collision-based back pressure function for full duplex operation
Supports up to 32K MAC addresses table/hashing algorithm on address learning
Supports 2Mbytes packet buffer per device
Broadcast storm control
Port Trunking (2 Trunk Groups) with 2, 3, 4, 5, 6, 7, or 8 designated 10/100Mbps ports
Port-based VLAN
Supports IEEE 802.1p Port-Based Quality of Service (QoS)
Console Port (cable included) for easy configuration with Windows-Based GUI (for Win95/98/ME)
Extensive front-panel diagnostic LED’s
5-year limited warranty


Hardware
Standards:	IEEE 802.3 10Base-T Ethernet, IEEE 802.3u 100Base-TX Fast Ethernet, IEEE 802.3ab 1000Base-T Gigabit Ethernet, IEEE 802.3z 1000Base-F Gigabit Ethernet, ANSI/IEEE 802.3 NWay Auto-Negotiation, IEEE 802.3x Full-Duplex Flow Control
Data Transfer Rate:	Ethernet: 10Mbps (Half-Duplex), 20Mbps (Full-Duplex) Fast Ethernet: 100Mbps (Half-Duplex), 200Mbps (Full-Duplex) Gigabit Ethernet: 1000Mbps (Half-Duplex),2000Mbps (Full-Duplex)
Cabling:	Ethernet: UTP CAT 3,4,5, EIA.ITA-568 100-ohm screened twisted pair (STP) Fast Ethernet: UTP CAT 5, EIA/TIA-568 100-ohm screened twisted pair (STP) Gigabit Ethernet: UTP CAT 5, EIA/TIA-568 100-ohm screened twisted pair (STP)
Protocol:	CSMA/CD
Topology:	Star
Data RAM Buffers:	2Mbit per Device
Filtering Address Table:	32K entries per device
Diagnostic LEDs:	Power, 10M Link/Act, 100M Link/Act, 1000M Link/Act
Power Consumption:	100~240 VAC 50/60hz, Internal Universal Power Supply
Dimensions:	440 x 200 x 44mm (W x H x D)
Temperature:	Operating Temp.: 0° to 50°C (32° to 122° F) Storage Temp.:-5° to 55° C (23° to 131° F)
Humidity:	5 % to 90 % non-condensing
Certifications:	FCC Class A, CE Class A, VCCI-A

Information provided in this document pertain to TRENDnet products and is subject to change at any time, without notice.
