TRENDnet | Products | Storage Servers

Product Families » Storage » Storage Servers » TS-U200

USB Network Storage Server w/ Memory Card Reader
TS-U200

Access the storage server from the Internet
Expand and manage your storage capacity in minutes
Built in card readers allow you to transfer pictures, music and more directly to your storage drives

DISCONTINUED PRODUCT

The TS-U200 has been discontinued. It has been replaced by the TS-I300 (Version 1.0R). For a list of discontinued products, click here.

Click on image to enlarge

The TS-U200 Network Storage Server is a quick and easy economical solution that adds storage to your existing network. It includes a built in Card reader that accommodates various types of memory cards, a Web based utility for IP filtering, a FTP Server service, and supports network time protocol (NTP).

Compliant with USB 1.1 and USB 2.0
Built-in-one 10/100Mbps auto-MDIX fast Ethernet LAN Port and 2 USB 2.0 ports
Equipped with all-in-1 Memory Card Reader/Writer
Provides Open mode and Account Mode
Acts as DHCP client to locate IP from DHCP server or Auto-IP
Provides FTP Server for remote access
Automatic download scheduling back up support
Supports USB 2.0 external disk drive, flash disk, and CD-ROM storage devices
Provides windows or web based configuration
Security with IP address filtering to ALLOW or DENY access
Automatically self tests the circuits of Flash Memory, DRAM, Ethernet Port, and USB 2.0 Ports when power is on
User account management
Supports Windows 98/98(SE)/ME/NT/2000/XP and Linux SMB Operation System
Web based administrative program stored into flash ROM of the server
Supports UPnP for Windows XP
Supports Network Time Protocol to track data access
2-year limited warranty

Hardware
Standards:	IEEE 802.3, IEEE 802.3u, USB 1.1
Supported Memory Card	CF: Compact Flash Card Type I/II SM: Smart Media Card MS: Memory Stick, Memory Stick PRO, Memory Stick DUO, Memory Stick PRO DUO SD: Secure Digital MMC: MultiMedia Card IBM MicroDrive
LEDs	Power, LAN, Mode, Backup
Power Consumption	5V DC, 2.5A External Power Adapter
Buttons	Reset, Unmount, Backup button
Dimensions (L x W x H)	157 x 125 x 30 mm (6.2 x 4.9 x 1.2 in)
Weight	250g (8.8oz.)
Temperature	Operation: 5°C ~ 50°C (41°F ~ 122°F) Storage: -20°C ~ 50°C (-4°F ~ 122°F)
Humidity	Operation: 10% - 90% Storage: 5% - 95%(Non-Condensing)
Certification	CE, FCC
Firmware Specification
Standard	IEEE802.e, IEEE802.3u, USB2.0, USB1.1
DHCP Client	Assigns IP address from DHCP server, Auto-IP
File System Type	Type Fat16 / Fat32
Security	IP Filtering; User Account Management

Information provided in this document pertain to TRENDnet products and is subject to change at any time, without notice.

Additional Info

Email a Friend

Datasheet

Quick Installation Guide

Downloads

Package Contents

TS-U200
Quick Installation Guide
CD-ROM (UG & Utility)
Power Adapter (5V DC, 2.5 A)
