24-Port 10/100/1000Mbps Copper Gigabit Switch
TEG-S240TX

DISCONTINUED PRODUCT

The TEG-S240TX has been discontinued. It has been replaced by the TEG-S240TX (Version E1.0R). For a list of discontinued products, click here.

Click on image to enlarge

TRENDnet´s TEG-S240TX is a high performance 24-port rack mountable Copper Gigabit Switch. With auto-negotiation technology, the TEG-S240TX automatically negotiates between 10Base-T, 100Base-TX and 1000Base-T network speeds, as well as half and full duplex modes. The Auto-MDIX feature on each port automatically detects and adjusts connection type with either straight-through or crossover cable. Providing simple migration, scalability, and flexibility to handle new applications and data types, TRENDnet´s TEG-S240TX is a highly reliable and cost effective solution for high-speed network applications.

24 10/100/1000Mbps Auto Negotiation and Auto-MDIX Ethernet Ports
Full/Half duplex transfer mode for each port (full duplex mode for 1000Base-T only)
Store and Forward switching method
20Gbps Backplane
Integrated address Look-Up Engine, supports 32k absolute MAC Address
Supports 2 Mbytes RAM for data buffering
Extensive Front Panel Diagnostic LEDs
Broadcast Storm protection
IEEE 802.3x flow control for full-duplex
Back Pressure flow control for half-duplex
Standard 19” rack-mount size
5-year limited warranty


Hardware
LAN Standards:	IEEE 802.3 10Base-T, 802.3u 100Base-TX and 802.3ab 1000Base-T
Cabling:	Ethernet: Cat. 3, 4, 5, UTP/STP. EIA/TIA-568 100 ohm, 100 meters max. Fast Ethernet: Cat. 5, UTP/STP, EIA/TIA-568 100 ohm, 100 meters max. Gigabit Ethernet: Cat.5 or better, UTP/STP, EIA/TIA-568 100ohm, 100 meters max.
Protocol:	CSMA/CD
Topology:	Star
Data Transfer Rates:	Ethernet: 10Mbps (Half-Duplex), 20Mbps (Full-Duplex) Fast Ethernet: 100Mbps (Half-Duplex), 200Mbps (Full-Duplex) Gigabit Ethernet: 2000Mbps (Full-Duplex)
Data RAM Buffers:	2MB per device
Filtering Address Table:	32K entries per device
Diagnostic LEDs:	Power, Link/Act, 1000M, 100M
Power Consumption:	100~240VAC 50/60Hz, Internal Universal Switching Power, 55 Watts. Max.
Dimensions:	440 x 210 x 44 mm (17.3 x 8.27x 1.73 inch) (W x H x D)
Weight:	3Kg (6.6 lb)
Temperature:	Operating: 0° ~ 40° C (32° ~ 104°F). Storage: -10° ~ 70° C (14° ~ 158°F)
Humidity:	10% ~ 90% (non-condensing)
Certifications:	FCC, CE

Information provided in this document pertain to TRENDnet products and is subject to change at any time, without notice.
