Home Smart Switch
(with Wireless Extender)

THA-101 (Version v1.0R)

  • Quick app-based setup
  • Turn a device on/off from any mobile internet connection
  • Powerful N300 wireless repeater extends your existing wireless network
  • Create a weekly on/off schedule
  • Free Apple® and Android™ app
  • Requires a home wireless network

TRENDnet's Home Smart Switch with Wireless Extender, model THA-101, is a combination smart electrical outlet and powerful N300 wireless extender. Use the free Apple® or Android™ mobile app from any internet connection to turn on and off a light, fan, electronic device, or appliance. Create a daily schedule to turn on/off the outlet to match your needs or to give the illusion that you're home. Place the THA-101 in an area of your home with low wireless coverage – the powerful built-in N300 wireless extender connects to your existing wireless router and broadcasts a strong wireless network.

A person uses a smartphone to control a smart switch and wireless extender. The smartphone screen displays an application interface with a large power button and some text. In the background, there is a close-up of a TRENDnet THA-101 smart switch and wireless extender plugged into a wall socket. The smart switch is connected to a floor lamp, which can be turned on or off using the wireless extender. This setup highlights the convenience and functionality of remotely controlling home appliances through a smart device.
Power Controller

Quick App-Based Setup

Complete the intuitive app-based setup in minutes

Remote Power Control

Turn a light, fan, electronic device, or appliance on/off from any mobile internet connection

On/Off Schedule

Create a weekly on/off schedule for a light, fan, or another device to match your needs or to give the illusion that you're home

No Clutter

The compact form factor stays off the ground by plugging directly into an outlet

Free App

TRENDnet's free Apple®and Android™app controls multiple THA-101 units from any internet connection

Power Consumption

See how much power your device is consuming with real-time electrical consumption information listed within the app

Over Current Protection

Trips relay when current exceeds 16 Amps

Power Controller

Wireless Extender

Extends the range of your existing Wireless network

N300 Wireless

Proven 300 Mbps Wireless N

Wireless Coverage

Extended wireless coverage with MIMO antenna technology

One Touch Connection

Securely connect to the router at the touch of the Wi-Fi Protected Setup (WPS) button

LED Indicators

LED indicators convey device status

Compatibility

Works with Wireless N and G routers

Smart Home App
  • Quick in-app THA-101 installation
  • Power on/off the electrical outlet from any internet connection
  • Create weekly on/off electrical outlet schedule
  • View real time power consumption: Energy (KWh), current (A), voltage (V), power (W)
  • Manage multiple THA-101 units from the app
Hardware Standards
  • IEEE 802.11b
  • IEEE 802.11g
  • IEEE 802.11n (up to 300 Mbps)
Device Interfaces
  • Electrical outlet
  • WPS button
  • Power switch
  • LED indicators
  • Reset button
Special Features
  • Overcurrent protection
  • Requires existing wireless network in order to function
Encryption
  • Wireless encryption: WEP, WPA/WPA2-PSK
Media Access Protocol
  • CSMA/CA with ACK
Antenna Gain
  • 2 x 2 dBi
Frequency
  • 2.412 - 2.484 GHz
Wireless Channels
  • FCC: 1-11, ETSI: 1-13
Modulation
  • 802.11b: CCK (11 Mbps & 5.5 Mbps), DQPSK (2 Mbps), DBPSK (1 Mbps)
  • 802.11g: OFDM with BPSK, QPSK and 16/64-QAM
  • 802.11n: BPSK, QPSK, 16-QAM, 64-QAM with OFDM
Wireless Output Power (EIRP)/Receiving Sensitivity
  • 802.11b: 17 dBm (typical)/-84 dBm (typical) @ 11 Mbps
  • 802.11g: 14 dBm (typical)/-73 dBm (typical) @ 54 Mbps
  • 802.11n: 14 dBm (typical)/-70 dBm (typical) @ 300 Mbps
Power
  • 100 - 240 V AC, 50 /60 Hz
  • Consumption: 6 Watts max.
Power Capacity
  • US: 1800 Watts / 15 Amps
  • EU/UK: 3120 Watts / 13 Amps
Operating Temperature
  • 0 - 40 °C (32 – 104 °F)
Operating Humidity
  • Max. 95% non-condensing
Certifications
  • CE
  • FCC
Dimensions
  • 93 x 58 x 37 mm (3.7 x 2.3 x 1.46 in.)
Weight
  • US: 138 g (4.9 oz.)
  • EU: 156 g (5.5 oz.)
  • UK: 160g (5.6 oz.)
Warranty
  • 3 year limited

PACKAGE CONTENTS
  • THA-101
  • Multi-Language Quick Installation Guide
  • CD-ROM (User's Guide)

* Maximum wireless signal rates are referenced from IEEE 802.11 theoretical specifications. Actual data throughput and coverage will vary depending on interference, network traffic, building materials and other conditions.

All references to speed are for comparison purposes only. Product specifications, size, and shape are subject to change without notice, and actual product appearance may differ from that depicted herein.

8/13/2015
