16-Port 10Base-T Ethernet Hub

TE-1710   (Version 1.0)

  • High performance 16 port Ethernet hub
  • Data rates up to 10Mbps
  • Enjoy a 5-year user warranty

DISCONTINUED PRODUCT

The TE-1710 (Version 1.0) has been discontinued. For a list of discontinued products, click here.

Datasheet

Datasheet
Filename: Spec_TE-1710.pdf
Date: 5/2/2013
File Size: 137.83 KB
Download Email

User's Guide

Manual
Filename: UG_TE-1710.pdf
Date: 8/20/2004
File Size: 299.21 KB
Download
Hardware
Speed:
  • 10Mbps
Ports:
  • 16 RJ45 UTP/STP port, 1 BNC port
Power:
  • 7.5 VDC, 1A
Dimensions:
  • 305 x 102 x 30 (mm) 12.0"x4.0"x1.18" (L x W x H)
Weight:
  • 625g / 1.38 lb
Temperature:
  • Operating: 0° C-50° C (32° F-122° F)
  • Storage: -20° C-70° C (-4° F-158° F)
Humidity:
  • Operating: 10%-80%
  • Storage: 5%-90%
Certifications:
  • FCC, UL, CE

All references to speed are for comparison purposes only. Product specifications, size, and shape are subject to change without notice, and actual product appearance may differ from that depicted herein.
