Enjoy crystal clear interference-free sound quality from this compact device
Connect wirelessly up to 10 meters (32.8 ft.) away
DISCONTINUED PRODUCT
The TBW-101UB (Version 2.1) has been discontinued.
It has been replaced by the TBW-107UB (Version v2.0R).
For a list of discontinued products, click here.
Please select the material to download according to your version of TBW-101UB. There are 4 versions of this product. To find out which version you have, look at the Serial Number on the bottom of the unit. Follow the illustrations bellow. Click on your version of the TBW-101UB to view available downloads
Step 1 Please consult with your Mobile Phone's manufacturer,
make sure your Mobile Phone supports the "Bluetooth Dial-up Networking Service"
and turn on the phone's "Bluetooth" service.
Below is an example on how to turn on the Mobile Phone's Bluetooth service
with "Motorola Razor V3" phone....
Step 1 Please consult with your Mobile Phone's manufacturer,
make sure your Mobile Phone supports the "Bluetooth Dial-up Networking Service"
and turn on the phone's "Bluetooth" service.
Below is an example on how to turn on the Mobile Phone's Bluetooth service
with "Motorola Razor V3" phone....
Uninstall the Air2U Bluetooth device in the Device Manager and reinstall the
utility.
Step 1 Right-Click on My Computer and click on Properties.
Step 2 Click on the Hardware tab.
Step 3 Click on the Device Manager
.
Step 4 Double-click on Bluetooth USB.
Step 5 Right-click on the Air2U ...
Step 1 Double-click the Bluetooth icon in your System Tray.
Step 2 Click the orange ball to search for Bluetooth devices
Step 3 Double Click the Bluetooth enabled device. All available Bluetooth
services are highlighted in yellow for your convenience. Double-click the Bluetooth
service yo...
You need to make sure your Cell Phone is Bluetooth enhanced and the software for the phone can allow you to transfer files. If yes, find the detail information from the User's Guide on the CD-ROM or additional....
Please follow the Remove Bluetooth USB Adapter procedures on the User's Guide to remove the Bluetooth USB Adapter and reinstall it Again....
Hardware
Adapter Standards
USB 1.1, Bluetooth 1.1 and 1.2
Antenna
2dBi
Link Mode
ACL and SCO
TX Output
Class II Operation
Supported OS
Windows 98SE/ME/2000/XP/2003 Server
Mac OS X 10.2.8 or above
Cable Length
15cm(6in.)
LED Indicator
Power
Operating Voltage
5V USB Power
Power Consumption
80mA (Max.)
Temperature
Operation: 0°;~ 55°C (32°F~132°F)
Storage: -20°~ 55°C (-4°F~132°F)
Humidity
70% (Max)
Dimensions
57 x 18 x 11 mm (2.24 x 0.71 x 0.43in.)
Weights
11 g (0.4 oz.)
Certification
CE, FCC
Wireless
Frequency
2.4~2.4835 GHz
Module Technique
Gaussian Frequency Shift Keying ( GFSK)
Output Power
0dBm (typical)
Receiving Sensitivity
- 82dBm ( typical )
Data Rate
Up to 723Kbps in ACL mode; up to 64Kbps in SCO mode
Date Range
Up to 25m (82 ft.) depends on the environment
PACKAGE CONTENTS
TBW-101UB
Multi-Language Quick Installation Guide
Driver CD-ROM
USB Cable
All references to speed are for comparison purposes only. Product specifications, size, and shape are subject to change without notice, and actual product appearance may differ from that depicted herein.
