Wireless Presenter

TU-P1W   (Version 1.0R)

  • Control the mouse, present PowerPoint presentations, adjust the volume and play videos with the intuitive wireless controls
  • Increase the impact of your presentation with this wireless device
  • Use the built in laser to highlight presentation content

DISCONTINUED PRODUCT

The TU-P1W (Version 1.0R) has been discontinued. For a list of discontinued products, click here.

Datasheet

Filename: EN_Spec_TU-P1W.pdf
Date: 10/31/2006
File Size: 321.50 KB
Filename: FR_Spec_TU-P1W.pdf
Date: 10/31/2006
File Size: 322.44 KB
Filename: GE_Spec_TU-P1W.pdf
Date: 10/31/2006
File Size: 303.77 KB
Filename: SP_Spec_TU-P1W.pdf
Date: 10/31/2006
File Size: 332.59 KB
Filename: RU_Spec_TU-P1W.pdf
Date: 10/31/2006
File Size: 378.50 KB

Quick Installation Guide

Filename: EN_QIG_TU-P1W.pdf
Date: 8/24/2006
File Size: 279.62 KB
Filename: FR_QIG_TU-P1W.pdf
Date: 8/24/2006
File Size: 284.01 KB
Filename: GE_QIG_TU-P1W.pdf
Date: 8/24/2006
File Size: 280.23 KB
Filename: PO_QIG_TU-P1W.pdf
Date: 9/7/2007
File Size: 383.78 KB
Filename: SP_QIG_TU-P1W.pdf
Date: 8/24/2006
File Size: 281.58 KB
Filename: RU_QIG_TU-P1W.pdf
Date: 8/24/2006
File Size: 712.93 KB

Product Images

JPEG Image
File Size: : 491.23 KB
Date: : 10/20/2006
JPEG Image
File Size: : 511.00 KB
Date: : 10/20/2006
JPEG Image
File Size: : 281.85 KB
Date: : 10/20/2006
TIFF Image
File Size: : 3.70 MB
Date: : 10/20/2006
TIFF Image
File Size: : 4.13 MB
Date: : 10/20/2006
TIFF Image
File Size: : 3.63 MB
Date: : 10/20/2006
ROHS compliant WEEE crossed-out bin symbol.
Hardware
Frequency 2.4GHz ISM Band
StandardUSB 1.1
Supported OSWindows 98SE/ME/2000/XP/2003 Server
Laser Wavelength
(Peak)
650nm + 20nm (Red Light)
Operation DistanceUp to 15 meters (49 feet)
Power Source2 AAA (1.5 V) batteries included
Power Consumption
  • Presenter: 3V 1.2mA
  • Presenter with Laser Pointer: 3V 27mA
  • Receiver: 5V 30mA
  • Laser Pointer: 1mW
Dimension
  • Receiver: 115 x 35 x 27mm (4.5 x 1.4 x 1.1in.)
  • Presenter: 65 x 20 x 10mm (2.6 x 0.8 x 0.4 in.)
Weight
  • Receiver: 45g (1.6 oz.)
  • Presenter: 10g (0.4oz.)
Temperature
  • Operation: 0° C ~ 55° C (32° F~ 131° F)
  • Storage: -20° C ~ 55° C (-4° F~ 131° F)
Humidity5%~ 90 %
CertificationFCC, CE

PACKAGE CONTENTS

  • TU-P1W
  • TU-P1W Presenter
  • TU-P1W Receiver

All references to speed are for comparison purposes only. Product specifications, size, and shape are subject to change without notice, and actual product appearance may differ from that depicted herein.
