10/100Mbps Multi-Protocol USB Print Server

TE100-PS1U   (Version 1.0)

  • This multiprotocol print server transforms virtually all stand-alone USB printer into a shared network printer
  • Full 100Mbps connectivity significantly boosts network printer performance
  • Enjoy a 5-year warranty for peace of mind

DISCONTINUED PRODUCT

The TE100-PS1U (Version 1.0) has been discontinued. For a list of discontinued products, click here.

Utility

Utility
Filename: PS_Admin_LPR.zip
SHA-1 Checksum: 24BFEB6C5B88D0264B9243C6B1A863798CD790FD
Date: 7/25/2017
File Size: 1.85 MB
Download

Firmware

firmware
DO NOT upgrade firmware on any TRENDnet product using wireless connection.
Firmware upgrade over wireless connection may damage the product. Please perform firmware upgrade with "wired" network connection only

Firmware Version: v2.75
Release Date: March 2008
Filename: FW_TE100-PS1U(v2.75).zip
SHA-1 Checksum: 067A42A987C9F3FA3852ED1DBED299F945C967B3
Date: 7/25/2017
File Size: 317.92 KB
Download

Datasheet

Datasheet
Filename: Spec_TE100-PS1U.pdf
Date: 5/2/2013
File Size: 174.62 KB
Download Email

User's Guide

Manual
Filename: UG_TE100-PS1U.zip
Date: 8/19/2004
File Size: 3.98 MB
Download
Hardware
LAN Standards:
  • IEEE 802.3 10Base-T and IEEE 802.3u 100Base-TX
  • ANSI/IEEE 802.3 NWay auto-negotiation
LAN Port:
  • 10/100Mbps UTP/STP RJ-45 port
Printer Interface:
  • USB Type A Male, USB 1.1 compliant
Network Cables:
  • Cat. 3, 4, 5 UTP/STP for 10Base-T (100 meters max.)
  • Cat. 5 UTP/STP for 100Base-TX (100 meters max.)
Supported Protocols:
  • TCP/IP, NetBEUI, and AppleTalk/EtherTalk
LED Indicator:
  • Power, LAN, USB
Power:
  • External Power Supply, 5V DC 2.4A
Dimensions:
  • 90 x 90 x 40 mm (3.54 x 3.54 x 1.57 inches)
Weight:
  • 116 g. (4.1Oz.)
Temperature:
  • Operating: 0°~50°C (32°~122°F)
  • Storage: -25°~55°C (-13°~131°F)
Humidity:
  • Operating: 10%~90%
Storage:
  • 5%~95% (non-condensing @ 30°C/86°F)
Emissions:
  • FCC class B, CE class B, VCCI Class B

All references to speed are for comparison purposes only. Product specifications, size, and shape are subject to change without notice, and actual product appearance may differ from that depicted herein.
