Indoor/Outdoor 4MP H.265 Motorized Varifocal PoE IR Bullet Network Camera

TV-IP344PI   (Version v2.0R)

   Select Another Version
  • 4MP HD video (2560 x 1440) at 20 fps
  • Adjustable 2.8 – 12mm motorized varifocal lens
  • Optical Zoom: 4.2x
  • Digital Zoom: 4x
  • Smart covert Enhanced IR LEDs for night vision up to 30m (98 ft.)
  • Enhanced IR provides up to 30% increase in illuminant efficiency over traditional IR LED array technology
  • Outdoor IP67 weather rating
  • 120dB Wide Dynamic Range image balancing
  • Save installation costs with Power over Ethernet (PoE)
  • Program motion detection recording and email alerts
  • Micro SD card slot (up to 128GB)
  • Free iOS® and Android™ mobile apps

DISCONTINUED PRODUCT

The TV-IP344PI (Version v2.0R) has been discontinued. For a list of discontinued products, click here.

Firmware

Firmware
DO NOT upgrade firmware on any TRENDnet product using wireless connection.
Firmware upgrade over wireless connection may damage the product. Please perform firmware upgrade with "wired" network connection only

Firmware Version: 5.5.12 build 190305
Release Date: 3/2019
Notes:

  • Initial release

Filename: FW_TV-IP344PI_345PI_v2(5.5.12 build 190305).zip
SHA-1 Checksum: D1A8249461660E6323488F095ACBBB6E2DF264AC
Date: 4/24/2019
File Size: 19.27 MB
Download

Datasheet

Datasheet (English)
Filename: EN_datasheet_TV-IP344PI_(v2.0R).pdf
Date: 9/30/2021
File Size: 815.37 KB
Download Email
Datasheet (Français)
Filename: FR_datasheet_TV-IP344PI_(v2.0R).pdf
Date: 9/30/2021
File Size: 1.06 MB
Download Email
Datasheet (Deutsch)
Filename: GE_datasheet_TV-IP344PI_(v2.0R).pdf
Date: 9/30/2021
File Size: 827.97 KB
Download Email
Datasheet (Português)
Filename: PO_datasheet_TV-IP344PI_(v2.0R).pdf
Date: 9/30/2021
File Size: 1.06 MB
Download Email
Datasheet (Español)
Filename: SP_datasheet_TV-IP344PI_(v2.0R).pdf
Date: 9/30/2021
File Size: 1.40 MB
Download Email
Datasheet (Pусский)
Filename: RU_datasheet_TV-IP344PI_(v2.0R).pdf
Date: 9/30/2021
File Size: 1.20 MB
Download Email
Datasheet (Italiano)
Filename: IT_datasheet_TV-IP344PI_(v2.0R).pdf
Date: 9/30/2021
File Size: 1.22 MB
Download Email

Quick Installation Guide

Quick Installation Guide (English)
Filename: English_TV-IP344PI_IP345PI(V2).pdf
Date: 3/6/2019
File Size: 2.19 MB
Download
Quick Installation Guide (Français)
Filename: French_TV-IP344PI_IP345PI(V2).pdf
Date: 3/6/2019
File Size: 2.28 MB
Download
Quick Installation Guide (Deutsch)
Filename: German_TV-IP344PI_IP345PI(V2).pdf
Date: 3/6/2019
File Size: 1.63 MB
Download
Quick Installation Guide (Português)
Filename: Portuguese_TV-IP344PI_IP345PI(V2).pdf
Date: 3/6/2019
File Size: 1.62 MB
Download
Quick Installation Guide (Español)
Filename: Spanish_TV-IP344PI_IP345PI(V2).pdf
Date: 3/6/2019
File Size: 1.62 MB
Download
Quick Installation Guide (Pусский)
Filename: Russian_TV-IP344PI_IP345PI(V2).pdf
Date: 3/6/2019
File Size: 1.60 MB
Download
Quick Installation Guide (Italiano)
Filename: Italian_TV-IP344PI_IP345PI(V2).pdf
Date: 3/6/2019
File Size: 1.61 MB
Download

User's Guide

User's Guide
Filename: UG_TV-IP344PI (v2.0R).pdf
Date: 4/24/2019
File Size: 4.18 MB
Download

Product Images

PNG Image
File Size: : 2.15 MB
Date: : 3/5/2019
Download
ROHS compliant WEEE crossed-out bin symbol.
Lens
  • Focal length: 2.8 – 12 mm @ F1.6
  • Focal depth: 30cm to infinity
  • Motorized varifocal lens
  • Sensor: 1/3” 4MP CMOS sensor
  • WDR: 120 dB
  • Optical zoom: 4.2x
  • Digital zoom: 4x
Viewing Angle
  • Horizontal: 28˚ – 98˚ (wide – tele)
3-Axis Manually Adjustable Mount
  • Pan: 0° – 360°
  • Tilt: 0° – 90°
  • Rotate: 0° – 360°
Minimum Illumination
  • IR off: 0.01 lux
  • IR on: 0 lux
  • IR distance: 30m (98 ft.)
  • IR LED wavelength: 850nm
Compression
  • H.265 / H.265+
  • H.264 / H.264+
  • MJPEG
Resolution
  • Main stream: H.265+/H.265/H.264+/H.264: 2560 x 1440 up to 20 fps
  • Sub stream: H.265/H.264/MJPEG: 704 x 480 up to 20 fps
Standards
  • IEEE 802.1x
  • IEEE 802.3
  • IEEE 802.3u
  • IEEE 802.3x
  • IEEE 802.3af
Device Interface
  • 10/100Mbps PoE port
  • Power jack
Housing
  • IP67 weather rated
Network Protocol
  • IPv4, IPv6, UDP, TCP/IP
  • DHCP, NTP, DDNS, SMTP, FTP, LLTD
  • SNMP v1, v2c, v3, QoS/DSCP, IEEE 802.1X
  • NFS, SMB/CIFS
  • HTTP, HTTPS
  • PPPoE
  • UPnP, RTSP, RTP
Compliant Standard
  • ONVIF (Profile S, G, T)
Dimension
  • 105 x 105 x 245mm (4.1 x 4.1 x 9.6 in.)
Weight:
  • 1.03kg (2.3 lbs.)
Operating Temperature
  • -30° – 60° C (-22° – 140° F)
Humidity
  • Max. 90% non-condensing
Power
  • Input: PoE
  • Max. consumption: 11W
Power Adapter (optional model: 12VDC1A)
  • Input: 100 – 240V AC, 50/60Hz
  • Output: 12V DC, 1A external power adapter
Management Interface
  • Multi-language support: English, French, German, Spanish, and Portuguese
  • Image settings: Brightness, Contrast, Saturation, Sharpness, Exposure Time, Day/Night switch. Smart IR, BLC, WDR, white balance, Digital Noise Reduction, Mirror, Rotate, Scene Mode, Video Standard
  • WDR enhances video quality in high contrast daytime lighting
  • Digital Noise Reduction removes digital noise from the video signal
  • Recording: to computer, or SAMBA share
  • Time, date, and text overlay
  • IP Address Filter
  • Video Recording: scheduled, motion detection, and tamper detection
  • Motion detection: define up to three motion detection areas and motion sensitivity
  • Privacy masks: define custom privacy masks
  • Tamper detection function: email notification
  • Snapshot: real time snapshot and motion triggered
  • Supported dynamic DNS services: dyn.com and no-ip.com
  • Supports remote management
  • Compatible browsers: Chrome™ or Firefox® (live view resolution up to 1280 x 720), Internet Explorer®
Certifications
  • CE
  • FCC
Warranty
  • 3 year

PACKAGE CONTENTS
  • TV-IP344PI
  • Quick Installation Guide
  • Camera mounting hardware

All references to speed are for comparison purposes only. Product specifications, size, and shape are subject to change without notice, and actual product appearance may differ from that depicted herein.
