24-Port Gigabit Managed Layer 2 Switch

TL2-G244   (Version v2.0R)

   Select Another Version
  • Command Line and console inputs supported
  • SNMP (v1, v2c, v3), 802.1X, RSTP, and MSTP support
  • Supports Port Trunking, Mirroring, IGMP, Static and Dynamic VLAN, RMON, and more
  • Private/Voice VLAN, QoS, and bandwidth controls
  • 24 x Gigabit ports
  • 4 x shared SFP slots and a console port
  • 48 Gbps switching capacity
  • Fanless design
  • NDAA / TAA compliant (U.S. and Canada only)
NDAA/TAA Compliant

DISCONTINUED PRODUCT

The TL2-G244 (Version v2.0R) has been discontinued. It has been replaced by the TL2-G244 (Version v2.0R). For a list of discontinued products, click here.

Drivers/Utility

Utility (Web Smart Management)
Utility Version: 3.4
Release Date: 5/2014
OS Compatibility: Windows® 8.1, 8, 7, Vista, XP, Windows® 2003/2008 Server
Notes:
  • Initial Release

Filename: Utility_WebSmartManagement(v3.4).zip
SHA-1 Checksum: 93F95732EADC20E3C837A39C0D3C2ECBF5271D9C
Date: 7/28/2017
File Size: 1.43 MB
Download

Firmware

Firmware
Firmware Version: 2.02.08
Release Date: 9/2019
Note:
  • Added capability to specify port description
  • User account password maximum character length changed to 20
  • Fixed switch crash when configuring port mirror to LACP member port
  • Fixed SNMP error when configuring IP address
  • Fixed switch crash when assigning an IP address Class B subnet 128.0.x.x/16
  • Security fixes

Filename: FW_TL2-G244_v2(2.02.08).zip
SHA-1 Checksum: CB5B163CCEBD438F1886C39C9B15AA4D1D1A6B38
Date: 9/25/2019
File Size: 11.29 MB
Download

Other

MIB
MIB Version: 1.01.01
Release Date: 3/2017
Note:
  • Added support for MAC-Based VLAN in firmware 2.02.04
  • Added support for Protocol-Based VLAN in firmware 2.02.04
  • Added support for TC (Topology Change) Protect for spanning tree in firmware 2.02.04
  • Added support for MVR (Multicast VLAN Registration) in firmware 2.02.04
  • Added support for dynamic ARP inspection in firmware 2.02.04

Filename: MIB_TL2-G244_v2(1.01.01).zip
Date: 7/28/2017
File Size: 87.26 KB
Download

Datasheet

Datasheet (English)
Filename: EN_datasheet_TL2-G244(v2.0R).pdf
Date: 8/6/2015
File Size: 5.55 MB
Download Email
Datasheet (Français)
Filename: FR_datasheet_TL2-G244(v2.0R).pdf
Date: 6/17/2015
File Size: 5.25 MB
Download Email
Datasheet (Deutsch)
Filename: GE_datasheet_TL2-G244(v2.0R).pdf
Date: 6/17/2015
File Size: 5.20 MB
Download Email
Datasheet (Português)
Filename: PO_datasheet_TL2-G244(v2.0R).pdf
Date: 6/17/2015
File Size: 5.26 MB
Download Email
Datasheet (Español)
Filename: SP_datasheet_TL2-G244(v2.0R).pdf
Date: 6/17/2015
File Size: 5.23 MB
Download Email
Datasheet (Pусский)
Filename: RU_datasheet_TL2-G244(v2.0R).pdf
Date: 6/17/2015
File Size: 5.27 MB
Download Email
Datasheet (Italiano)
Filename: IT_datasheet_TL2-G244(v2.0R).pdf
Date: 6/17/2015
File Size: 5.19 MB
Download Email

Quick Installation Guide

Quick Installation Guide (English)
Filename: EN_Web_TL2-G244(V2.0R).pdf
Date: 9/3/2015
File Size: 2.73 MB
Download
Quick Installation Guide (Français)
Filename: FR_Web_TL2-G244(V2.0R).pdf
Date: 9/3/2015
File Size: 2.76 MB
Download
Quick Installation Guide (Deutsch)
Filename: GE_Web_TL2-G244(V2.0R).pdf
Date: 9/3/2015
File Size: 2.68 MB
Download
Quick Installation Guide (Português)
Filename: PO_Web_TL2-G244(V2.0R).pdf
Date: 9/3/2015
File Size: 2.65 MB
Download
Quick Installation Guide (Español)
Filename: SP_Web_TL2-G244(V2.0R).pdf
Date: 9/3/2015
File Size: 2.68 MB
Download
Quick Installation Guide (Pусский)
Filename: RU_Web_TL2-G244(V2.0R).pdf
Date: 9/3/2015
File Size: 2.69 MB
Download
Quick Installation Guide (Italiano)
Filename: ITA_Web_TL2-G244(V2.0R).pdf
Date: 9/3/2015
File Size: 2.68 MB
Download
Quick Installation Guide (Polski)
Filename: POL_Web_TL2-G244(V2.0R).pdf
Date: 9/3/2015
File Size: 2.70 MB
Download
Quick Installation Guide (Român)
Filename: RO_Web_TL2-G244(V2.0R).pdf
Date: 9/3/2015
File Size: 2.69 MB
Download
Quick Installation Guide (Nederlands)
Filename: NL_Web_TL2-G244(V2.0R).pdf
Date: 9/3/2015
File Size: 2.68 MB
Download
Quick Installation Guide (Magyar)
Filename: HUG_Web_TL2-G244(V2.0R).pdf
Date: 9/3/2015
File Size: 2.69 MB
Download

User's Guide

User's Guide
Filename: UG_TL2-G244(V2).pdf
Date: 5/11/2015
File Size: 3.98 MB
Download

Product Images

JPEG Image
File Size: : 595.21 KB
Date: : 4/13/2015
Download
JPEG Image
File Size: : 525.29 KB
Date: : 4/13/2015
Download
JPEG Image
File Size: : 443.49 KB
Date: : 4/13/2015
Download
JPEG Image
File Size: : 534.04 KB
Date: : 4/13/2015
Download
ROHS compliant WEEE crossed-out bin symbol.
Standards
  • IEEE 802.1d
  • IEEE 802.1p
  • IEEE 802.1Q
  • IEEE 802.1s
  • IEEE 802.1w
  • IEEE 802.1X
  • IEEE 802.1ab
  • IEEE 802.3
  • IEEE 802.3u
  • IEEE 802.3x
  • IEEE 802.3z
  • IEEE 802.3ab
  • IEEE 802.3ad
  • IEEE 802.3az
Device Interface
  • 24 x Gigabit ports (ports 1-24)
  • 4 x Shared SFP slots (shared with ports 21-24)
  • 1 x Console Port
  • LED indicators
Data Transfer Rate
  • Ethernet: 10 Mbps (half duplex), 20 Mbps (full duplex)
  • Fast Ethernet: 100 Mbps (half duplex), 200 Mbps (full duplex)
  • Gigabit Ethernet: 2000 Mbps (full duplex)
Performance
  • Switch fabric: 48 Gbps
  • RAM buffer: 1 MB
  • MAC Address Table: 16K entries
  • Jumbo Frames: 10 KB
  • HOL Blocking Prevention
  • Forwarding rate: 35.7 Mpps (64-byte packet size)
Management
  • CLI (Console)
  • HTTP/HTTPS (SSL v2/3 TLS) Web based GUI
  • SNMP v1, v2c, v3
  • RMON v1
  • Static Unicast MAC Address
  • Enable/disable 802.3az Power Saving
  • LLDP
  • Virtual Cable Test
  • IPv6: IPv6 Neighbor Discovery, IPv6 Static IP, DHCPv6, Auto configuration
MIB
  • MIB II RFC 1213
  • Bridge MIB RFC 1493
  • Bridge MIB Extension RFC 2674
  • SNMPv2 MIB RFC 1907
  • Ethernet Interface MIB RFC 1643
  • Ethernet –like MIB RFC 2863
  • Interface Group MIB RFC 2233
  • MIB Traps Convention RFC 1215
  • RMON MIB RFC 1757, RFC 2819
  • 802.1p MIB RFC 2674
  • RADIUS Client Authentication MIB RFC 2618
  • LLDP-MIB IEEE 802.1ab
  • Ping MIB RFC 2925, RFC 4560
Spanning Tree
  • IEEE 802.1D STP (Spanning Tree protocol)
  • IEEE 802.1w RSTP (Rapid Spanning Tree protocol)
  • IEEE 802.1s MSTP (Multiple Spanning Tree protocol)
Link Aggregation
  • Static Link Aggregation
  • 802.3ad Dynamic LACP
Quality of Service (QoS)
  • 802.1p Class of Service (CoS)
  • DSCP (Differentiated Services Code Point)
  • Bandwidth Control per port
  • Queue Scheduling: Strict Priority, Weighted Round Robin (WRR)
VLAN
  • Multiple management VLAN assignment
  • Asymmetric VLAN
  • 802.1Q Tagged VLAN
  • Dynamic GVRP
  • Up to 256 VLAN groups, ID Range 1-4094
  • Private VLAN (Protected Ports)
  • Voice VLAN (10 user defined OUIs)
Multicast
  • IGMP Snooping v1, v2, v3 (per VLAN)
  • Static Multicast Address
  • Up to 256 multicast entries
Port Mirror
  • RX, TX, or Both
  • One to one
Access Control
  • 802.1X Port-Based Network Access Control, RADIUS, TACACS+
  • Local Dial In User Authentication
  • DHCP Snooping (per VLAN)
  • Loopback Detection
  • Duplicated Address Detection
  • Trusted Host
  • Denial of Service (DoS)
ACL IPv4 L2-L4 & IPv6
  • MAC Address
  • VLAN ID
  • Ether Type (IPv4 only)
  • IP Protocol 0-255
  • TCP/UDP Port 1-65535
  • 802.1p
  • DSCP (IPv4 only)
  • IPv6 Address (IPv6 only)
Compatibility
  • Optional Software Utility: Windows® 8.1, 8, 7, Vista, XP, Windows® 2003/2008 Server
Special Features
  • Fanless Design
  • IPv6
  • 802.3az power saving
  • Rack mountable
Power
  • Input: 100 - 240 V AC, 50/60 Hz, internal power supply
  • Consumption: 15 Watts (max.)
Fan / Acoustics
  • Quantity: 0
  • Noise Level: 0 dB(A) (max.)
MTBF
  • 806,202 hours
Operating Temperature
  • 0 – 45°C (32 - 113°F)
Operating Humidity
  • Max. 90% non-condensing
Dimensions
  • 440 x 210 x 44.45 mm (17.3 x 8.27 x 1.75 in.)
  • Rack mountable 1U height
Weight
  • 2.8 kg (6.2 lbs.)
Certifications
  • CE
  • FCC
Warranty
  • 3 year limited

PACKAGE CONTENTS
  • TL2-G244
  • Quick Installation Guide
  • CD-ROM (Utility & User's Guide)
  • Power cord (1.8 m / 6 ft.)
  • Console cable (1.8 m / 6 ft.)
  • Rack mount kit

All references to speed are for comparison purposes only. Product specifications, size, and shape are subject to change without notice, and actual product appearance may differ from that depicted herein.
