4-Port Gigabit Switch with SFP Slot

TEG-S51SFP   (Version v1.1R)

   Select Another Version
  • 4 x Gigabit ports
  • 1 x SFP slot
  • 10 Gbps switching fabric
  • Quality of Service traffic prioritization (802.1p QoS)
  • Jumbo Frame support
  • Fanless design
  • Metal housing
  • Magnet Mount
  • NDAA / TAA compliant (U.S. and Canada only)
NDAA/TAA Compliant

DISCONTINUED PRODUCT

The TEG-S51SFP (Version v1.1R) has been discontinued. It has been replaced by the TEG-S51SFP (Version v2.0R). For a list of discontinued products, click here.

Datasheet

Datasheet (English)
Filename: EN_datasheet_TEG-S51SFP(v1.1R).pdf
Date: 5/5/2017
File Size: 819.27 KB
Download Email
Datasheet (Français)
Filename: FR_datasheet_TEG-S51SFP(v1.1R).pdf
Date: 5/5/2017
File Size: 1.75 MB
Download Email
Datasheet (Deutsch)
Filename: GE_datasheet_TEG-S51SFP(v1.1R).pdf
Date: 5/5/2017
File Size: 1.72 MB
Download Email
Datasheet (Português)
Filename: PO_datasheet_TEG-S51SFP(v1.1R).pdf
Date: 5/5/2017
File Size: 1.74 MB
Download Email
Datasheet (Español)
Filename: SP_datasheet_TEG-S51SFP(v1.1R).pdf
Date: 5/5/2017
File Size: 1.74 MB
Download Email
Datasheet (Pусский)
Filename: RU_datasheet_TEG-S51SFP(v1.1R).pdf
Date: 5/5/2017
File Size: 1.76 MB
Download Email
Datasheet (Italiano)
Filename: IT_datasheet_TEG-S51SFP(v1.1R).pdf
Date: 5/5/2017
File Size: 1.73 MB
Download Email

Quick Installation Guide

Quick Installation Guide (QIG)
Filename: lineart qig_TEG-S51SFP(v1.0R).pdf
Date: 9/28/2021
File Size: 3.20 MB
Download

Product Images

JPEG Image
File Size: : 847.90 KB
Date: : 5/5/2017
Download
JPEG Image
File Size: : 743.64 KB
Date: : 5/5/2017
Download
JPEG Image
File Size: : 711.83 KB
Date: : 5/5/2017
Download
JPEG Image
File Size: : 323.52 KB
Date: : 5/5/2017
Download
ROHS compliant WEEE crossed-out bin symbol.
Standards
  • IEEE 802.1p
  • IEEE 802.3
  • IEEE 802.3u
  • IEEE 802.3x
  • IEEE 802.3ab
  • IEEE 802.3z
Device Interfaces
  • 4 x Gigabit Ethernet ports
  • 1 x SFP slot
  • LED indicators
  • Wall Mount
Data Transfer Rate
  • Ethernet: 10 Mbps (half duplex), 20 Mbps (full duplex)
  • Fast Ethernet: 100 Mbps (half duplex), 200 Mbps (full duplex)
  • Gigabit: 2000 Mbps (full duplex)
Performance
  • Data RAM Buffer: 128 KB
  • Switch Fabric: 10 Gbps
  • MAC Address Table: 2K entries
  • Jumbo Frame: 9 KB
  • Forwarding rate: 7.44 Mpps (64-byte packet size)
Special Feature
  • Rugged metal enclosure with magnet mount
  • Gigabit SFP slot
Power
  • Input: 100 – 240 V AC, 50 / 60 Hz
  • Output: 5 V DC, 1 A
  • Max. consumption: 0.8 Watts
MTBF
  • 1,033,343 hours
Operating Temperature
  • 0 – 40 °C (32 – 104 °F)
Operating Humidity
  • Max. 90% non-condensing
Dimensions
  • 147 x 105 x 28 mm (5.8 x 4.1 x 1.1 in.)
Weight
  • 434 g (15.3 oz)
Certifications
  • CE
  • FCC
Warranty
  • 3 year limited

PACKAGE CONTENTS
  • TEG-S51SFP
  • Quick Installation Guide
  • Power adapter (5 V DC, 1 A)
  • Magnet mounting kit

All references to speed are for comparison purposes only. Product specifications, size, and shape are subject to change without notice, and actual product appearance may differ from that depicted herein.
