Nome do arquivo: Spec_TEG-S40TXD(English).pdf
Data: 3/8/2005
Tamanho de arquivo: 340.99 KB
Nome do arquivo: Spec_TEG-S40TXD(French).pdf
Data: 3/8/2005
Tamanho de arquivo: 345.15 KB
Nome do arquivo: Spec_TEG-S40TXD(German).pdf
Data: 3/8/2005
Tamanho de arquivo: 345.05 KB
Nome do arquivo: SP_Spec_TEG-S40TXD.pdf
Data: 11/30/2005
Tamanho de arquivo: 344.15 KB
Nome do arquivo: UG_TEG-S40TXD.pdf
Data: 8/18/2004
Tamanho de arquivo: 70.83 KB
JPEG Image
Tamanho de arquivo: : 73.63 KB
Data: : 9/1/2004
TIFF Image
Tamanho de arquivo: : 2.20 MB
Data: : 9/1/2004
Padrões: | - IEEE 802.3 10Base-T Ethernet
- IEEE 802.3u 100Base-TX Fast Ethernet
- IEEE 802.3ab 1000Base-T Gigabit Ethernet
- ANSI/IEEE 802.3 NWay Auto-Negotiation
- IEEE 802.3x Full-Duplex Flow Control
|
---|
Data Transfer Rate: | - Ethernet: 10 Mbps (Half-Duplex), 20 Mbps (Full-Duplex),
- Fast Ethernet: 100 Mbps (Half-Duplex), 200 Mbps (Full-Duplex),
- Gigabit Ethernet: 2000 Mbps (Full-Duplex)
|
---|
Cabeamento: | - Ethernet: Cat. 3,4,5, UTP/STP, EIA.ITA-568 100 ohm
- Fast Ethernet: Cat. 5, UTP/STP EIA/TIA-568 100 ohm
- Gigabit Ethernet: Cat. 5, UTP/STP, EIA/TIA-568 100 ohm
|
---|
Comprimento do Cabo: | |
---|
Protocolo: | |
---|
Topologia: | |
---|
Data RAM Buffers: | |
---|
Tabela Endereço de Filtros: | - 8K entradas por dispositivo
|
---|
LEDs Diagnóstico: | - Power, LINK/ACT, 100M, 1000M
|
---|
Alimentação: | - 100~240 VAC 50/60hz, Fonte de Alimentação Chaveada Universal Interna, 12 Watts max.
|
---|
Dimensões: | - 280× 180 × 44 mm (11“ x 7.1“ x 1.73“)
|
---|
Peso: | |
---|
Temperatura: | - Operação: 0 °C ~ 40°C (32°~104°F)
- Armazenamento: -10°C ~ 55°C (14°~131°F)
|
---|
Umidade: | - 5 % to 95 % RH sem condensação
|
---|
Certificados: | - CE Class A, FCC Class A, VCCI-A
|
---|
Todas as referências à velocidade são apenas para fins comparativos. As especificações, tamanho e formato do produto estão sujeitos a alterações sem aviso prévio, e a aparência real do produto pode ser diferente da descrita aqui.
