108Mbps Wireless Super G USB Adapter
TEW-444UB (Version V1.1R)
- Share a wireless network with your PC or laptop in minutes
- 2x the speed of wireless g* with XR technology
- Advanced wireless encryption provides robust security
DISCONTINUED PRODUCT
The TEW-444UB (Version V1.1R) has been discontinued. It has been replaced by the TEW-809UB (Version v1.0R). For a list of discontinued products, click here.Utility
Nome do arquivo: Driver_TEW-444UB(V1).zip
SHA-1 Checksum: 575F34BA2E905C1DA13DEA742A8D29A735D6BFF9
Data: 7/26/2017
Tamanho de arquivo: 17.52 MB
Ficha técnica
Nome do arquivo: EN_Spec_TEW-444UB(V1.1).pdf
Data: 7/17/2009
Tamanho de arquivo: 467.22 KB
Nome do arquivo: FR_Spec_TEW-444UB(V1.1).pdf
Data: 7/17/2009
Tamanho de arquivo: 471.05 KB
Nome do arquivo: GE_Spec_TEW-444UB(V1.1).pdf
Data: 7/17/2009
Tamanho de arquivo: 472.66 KB
Nome do arquivo: SP_Spec_TEW-444UB(V1.1).pdf
Data: 7/17/2009
Tamanho de arquivo: 470.57 KB
Nome do arquivo: RU_Spec_TEW-444UB(V1.1).pdf
Data: 7/17/2009
Tamanho de arquivo: 1.22 MB
Guia de Instalação Rápida
Nome do arquivo: EN_QIG_TEW-444UB.pdf
Data: 5/21/2009
Tamanho de arquivo: 532.79 KB
Nome do arquivo: FR_QIG_TEW-444UB.pdf
Data: 5/21/2009
Tamanho de arquivo: 533.59 KB
Nome do arquivo: GE_QIG_TEW-444UB.pdf
Data: 5/21/2009
Tamanho de arquivo: 532.78 KB
Nome do arquivo: PO_QIG_TEW-444UB.pdf
Data: 5/16/2013
Tamanho de arquivo: 587.29 KB
Nome do arquivo: SP_QIG_TEW-444UB.pdf
Data: 5/21/2009
Tamanho de arquivo: 534.83 KB
Nome do arquivo: RU_QIG_TEW-444UB.pdf
Data: 5/16/2013
Tamanho de arquivo: 680.76 KB
Nome do arquivo: CN_QIG_TEW-444UB.pdf
Data: 5/16/2013
Tamanho de arquivo: 1.29 MB
Guia do Usuário
Nome do arquivo: UG_TEW-444UB.pdf
Data: 5/21/2009
Tamanho de arquivo: 899.75 KB
Frequently Asked Questions (FAQ)
Imagem(ns) do Produto
Linux is not a supported operating system. The following is the chipset for the TEW-444UB: Atheros AR5523 + AR2112. Check with the chipset manufacturer to see if Linux drivers are available....
Make sure the Wireless zero configuration service is running.
Step 1: Click on Start then Run. Type in "services.msc", without the quotes and hit enter.
Step 2: This will open the services window. Double click on the Wireless zero configuration service.
Step 3: Make sure the Startup...
WEP or WPA encryption is not setup on the wireless network that you are connected to.
There are a number of factors that can impact the range of wireless devices.
Keep the number of obstructions to a minimum. Each obstruction can reduce
the range of a wireless device. Position the wireless devices in a manner
that will minimize the amount of obstructions between them.
B...
The Wireless Zero Configuration service is not running. Click on Start then Run.
Type in "services.msc", without the quotes and hit enter.
This will open the services window. Double click on the Wireless zero configuration
service.
Make sure the Startup type is set to Automatic and c...
The "Windows Wireless Zero Configuration Utility" is controlling the adapter.
Click on Start then Run and type in "ncpa.cpl", without the quotes and hit enter.
This will open the Network Connections window. Right click on your wireless network
connection and click on properties.
...
Open the utility by right clicking on the icon at the bottom right hand side of the screen and going to Open 802.11g Client utility.
Click on the Profile Management tab of the Wireless Configuration Utility, hightlight the profile you want to modify and click modify.
Then select what type of e...
Peer-to-peer wireless connection between computers when no router or access point is used
Windows Vista
Step 1: On the bottom right-hand corner of the screen, right click the wireless network connection icon and select "Connect
to a network".
Step 2: Select the desired network and then click "Connect".
Step 3: Enter the security key and then click "Connect".
Note: If you a...
| Hardware | |
| Interface: | USB 2.0, 1.1 Compliant |
|---|---|
| Standards: | IEEE802.11b and IEEE 802.11g |
| Power Consumption: | 450mA @ 5V DC |
| Supported OS | Windows 98SE/ME/2000/XP (32-bit) / Vista (32/64-bit) |
| Dimensions (LxWxH) | 95 x 22 x 10 mm (3.7 x 0.87 x 0.4 inches) |
| Weight | 28 g (1 oz.) |
| Temperature | Operating: 0° ~ 40° C (32° ~ 104° F) |
| Humidity | 10% ~ 90%max (Non-condensing) |
| Emissions | FCC, CE |
| Wireless | |
| Module Technique: |
|
| Frequency: | 2.412 ~ 2.484 GHz |
| Media Access Protocol: | CSMA/CA |
| Data Rate (auto fallback): |
|
| Transmit Power: |
|
| Receiving Sensitivity: | 802.11b: 11Mbps 10 – 5 BER @ -82 dBm (typical) 802.11g: 54Mbps 10 – 5 BER @ -70 dBm (typical) |
| Encryption: | 64/128-bit WEP (Hex or ASCII), WPA (AES/TKIP) |
| Channels: | 1~11 (US), 1~13 (EU) |
 | |
CONTEÚDO DA EMBALAGEM |
|
Todas as referências à velocidade são apenas para fins comparativos. As especificações, tamanho e formato do produto estão sujeitos a alterações sem aviso prévio, e a aparência real do produto pode ser diferente da descrita aqui.
