NÃO atualize firmware em nenhum produto da TRENDnet utilizando conexão wireless Atualização de firmware sobre conexão wireless pode causar dano ao produto. Por favor execute a atualização de firmware somente com conexão cabeada. |
Release Note:Update from version 0.01.21.
- Added ADSL 2+ support.
- Fixed “PC-database” when selecting to edit "PC Name", the first PC name is selected instead.
- Adjusted page alignment for items in “PC-database”.
- Updated Dynamic DNS client for DYNDNS.ORG.
- Added “Modem” only mode.
Firmware Upgrade Instruction:
Please download and unzip the firmware file, then follow the instructions in the "readme.txt" to update the firmware.
Nome do arquivo: Firmware_TW100-BRM504_20004.zip
SHA-1 Checksum: 3BE1B81F8CF7EEF6C02EDC17725BB557C24E7E7D
Data: 7/28/2017
Tamanho de arquivo: 1.44 MB
Nome do arquivo: EN_Spec_TW100-BRM504.pdf
Data: 11/30/2005
Tamanho de arquivo: 178.69 KB
Nome do arquivo: FR_Spec_TW100-BRM504.pdf
Data: 11/30/2005
Tamanho de arquivo: 170.50 KB
Nome do arquivo: GE_Spec_TW100-BRM504.pdf
Data: 11/30/2005
Tamanho de arquivo: 182.64 KB
Nome do arquivo: SP_Spec_TW100-BRM504.pdf
Data: 11/30/2005
Tamanho de arquivo: 183.74 KB
Nome do arquivo: QIG_TW100-BRM504_EN.pdf
Data: 12/2/2005
Tamanho de arquivo: 2.92 MB
Nome do arquivo: QIG_TW100-BRM504_FR.pdf
Data: 10/27/2004
Tamanho de arquivo: 2.98 MB
Nome do arquivo: QIG_TW100-BRM504_GE.pdf
Data: 10/27/2004
Tamanho de arquivo: 2.98 MB
Nome do arquivo: QIG_TW100-BRM504_SP.pdf
Data: 10/27/2004
Tamanho de arquivo: 2.98 MB
Nome do arquivo: QIG_TW100-BRM504(b1)_IT.pdf
Data: 7/20/2005
Tamanho de arquivo: 1.15 MB
Nome do arquivo: QIG_TW100-BRM504(A1)(Hebrew).pdf
Data: 1/19/2006
Tamanho de arquivo: 3.77 MB
Nome do arquivo: UG_TW100-BRM504.pdf
Data: 11/2/2004
Tamanho de arquivo: 792.73 KB
JPEG Image
Tamanho de arquivo: : 358.58 KB
Data: : 11/10/2006
TIFF Image
Tamanho de arquivo: : 3.46 MB
Data: : 11/10/2006
Please check your hardware and TCP/IP settings again by following the instructions in sections 1-3, make sure the Power, WAN, and on the LAN LEDs are on. Then try to access the configuration page using your Web Browser again....
You can contact your Internet Service Provider (ISP)'s Customer Service or Technical Support Department for the correct information....
The power adapter might not be connected. Please connect the power adapter to the power outlet and check the LEDs again. Please note that using the wrong power adapter might physically damage the unit....
Padrões: | IEEE 802.3(10Base-T), 802.3u(100Base-TX) |
---|
Protocolos: | NAT/NAPT, PPPoE & PPPoA, HTTP, DHCP(cliente/servidor), TCP/IP &UDP, PAP&CHAP, RIP1, DDNS, UPnP |
---|
Firewall: | Firewall NAT, Firewall Policy Rule-Based, Alerta de Ataque (email) e registro, Firewall SPI(Stateful Packet Inspection) para Ataques DoS (Denial of Service) |
---|
Segurança: | FiltroURL, Controle de Acesso,Password Local |
---|
ATM: | Suporta AAL5, UBR, Escala VPI (0 ~ 255) e Escala VCI (1 ~ 65535), 1 PVC, OAM F4/F5 loop back. |
---|
Payload Encapsulation: | - RFC2684 (RFC1483), Multi-Protocolo sobre ATM; RFC2225 (RFC1577), IPoA
- RFC2364, PPP sobre ATM (CHAP&PAP); RFC2516, PPPoE sobre ATM
|
---|
Portas LAN: | 4 Portas Ethernet (RJ45) 10/100 Mbps, Auto-MDIX |
---|
Porta WAN: | - Compatível com Anexo A G.dmt (G.922.1)
- Compatível com Anexo A G.lite (G.922.1) e T1.413
- Interface de Linha ADSL (RJ11)
|
---|
Impedância: | 100 Ohm; Adaptação automática de taxa na etapa de 32 Kbps |
---|
LEDs: | Power, Status, 10/100 (LAN 1~4), WAN |
---|
Energia: | 15 VDC 1 A Adaptador de Energia Externo |
---|
Dimensões: | 183 x 125 x 31 mm (7.2 x 4.9 x 1.2') |
---|
Peso: | 408 g (0.9 lb) |
---|
Temperatura: | - Operação: 0° ~ 40° C (32° ~ 104° F)
- Armazenagem: -20° ~ 70° C (-4° ~ 158° F)
|
---|
Umidade: | - Operação: 10 ~ 90% RH
- Armazenagem: 5 ~ 95% RH
|
---|
Certificados: | FCC, CE |
---|
Todas as referências à velocidade são apenas para fins comparativos. As especificações, tamanho e formato do produto estão sujeitos a alterações sem aviso prévio, e a aparência real do produto pode ser diferente da descrita aqui.
