Nome do arquivo: Spec_TEG-S28TX(English).pdf
Data: 12/23/2004
Tamanho de arquivo: 206.08 KB
Nome do arquivo: Spec_TEG-S28TX(French).pdf
Data: 1/17/2005
Tamanho de arquivo: 339.95 KB
Nome do arquivo: Spec_TEG-S28TX(German).pdf
Data: 2/9/2005
Tamanho de arquivo: 342.02 KB
Nome do arquivo: SP_Spec_TEG-S28TX_.pdf
Data: 11/30/2005
Tamanho de arquivo: 355.24 KB
Nome do arquivo: UG_TEG-S28TX.pdf
Data: 8/18/2004
Tamanho de arquivo: 148.62 KB
JPEG Image
Tamanho de arquivo: : 190.79 KB
Data: : 9/1/2004
TIFF Image
Tamanho de arquivo: : 2.25 MB
Data: : 9/1/2004
Padrões: | - IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3ab 1000Base-T, ANSI/IEEE 802.3 NWay auto-negotiation, IEEE 802.3x Flow Control
|
---|
Cabeamento: | - Ethernet: UTP CAT 3, 4, 5, EIA/TIA-568 100 ohms, 100 meters (max.);
- Fast Ethernet: UTP CAT 5, EIA/TIA-568 100 ohms, 100 meters (max.);
- Gigabit Ethernet: 4-pair UTP CAT 5, EIA/TIA-568 100 ohms, 100 meters (max.)
|
---|
Protocolo: | |
---|
Topologia: | |
---|
Taxa de Transferência de Dados: | - Ethernet: 10 Mbps Half-Duplex, 20 Mbps Full-Duplex
- Fast Ethernet: 100 Mbps Half-Duplex, 200 Mbps Full-Duplex
- Gigabit Ethernet: 2000 Mbps Full-Duplex
|
---|
Buffers Dados RAM: | - 256 KByte por dispositivo
|
---|
Tabela Filtros Endereço: | - 6K entradas por dispositivo
|
---|
LEDs de Diagnóstico: | - Power, Speed, Link/Act, FDX/COL
|
---|
Alimentação: | - 100~240VAC 50/60Hz, Fonte de Alimentação Chaveada Universal Interna
|
---|
Consumo: | |
---|
Dimensões: | - 280 x 180 x 44 mm (11 x 7.1 x 1.73")
|
---|
Peso: | |
---|
Temperatura: | - Operação: 0° - 50° C (32° a 122° F)
- Armazenagem: -10° - 70° C (14° a 158° F)
|
---|
Umidade: | - 10% - 90% (sem condensação)
|
---|
Emissão: | - FCC Class A, CE Mark A, VCCI-A
|
---|
Todas as referências à velocidade são apenas para fins comparativos. As especificações, tamanho e formato do produto estão sujeitos a alterações sem aviso prévio, e a aparência real do produto pode ser diferente da descrita aqui.
