Utility Version: 1.12b03
Release Date: 6/2014
Notes:
Nome do arquivo: UtilityDriver_TEW-703PI_PIL.zip
SHA-1 Checksum: F32F174D16DD30ADF92E00CCAB65AF45AB44E433
Data: 7/28/2017
Tamanho de arquivo: 20.61 MB
Nome do arquivo: EN_spec_TEW-703PIL(v1.1R).pdf
Data: 4/25/2017
Tamanho de arquivo: 736.55 KB
Nome do arquivo: FR_spec_TEW-703PIL(v1.1R).pdf
Data: 4/25/2017
Tamanho de arquivo: 737.21 KB
Nome do arquivo: GE_spec_TEW-703PIL(v1.1R).pdf
Data: 4/25/2017
Tamanho de arquivo: 740.35 KB
Nome do arquivo: SP_spec_TEW-703PIL(v1.1R).pdf
Data: 4/25/2017
Tamanho de arquivo: 747.78 KB
Nome do arquivo: RU_spec_TEW-703PIL(v1.1R).pdf
Data: 4/25/2017
Tamanho de arquivo: 737.02 KB
Nome do arquivo: IT_spec_TEW-703PIL(v1.1R).pdf
Data: 4/25/2017
Tamanho de arquivo: 737.45 KB
Nome do arquivo: EN_Web_TEW-703PI_703PIL(1.01).pdf
Data: 4/4/2017
Tamanho de arquivo: 1.78 MB
Nome do arquivo: FR_Web_TEW-703PI_703PIL(1.01).pdf
Data: 4/4/2017
Tamanho de arquivo: 1.86 MB
Nome do arquivo: GE_Web_TEW-703PI_703PIL(1.01).pdf
Data: 4/4/2017
Tamanho de arquivo: 1.32 MB
Nome do arquivo: PO_Web_TEW-703PI_703PIL(1.01).pdf
Data: 4/4/2017
Tamanho de arquivo: 1.75 MB
Nome do arquivo: SP_Web_TEW-703PI_703PIL(1.01).pdf
Data: 4/4/2017
Tamanho de arquivo: 1.32 MB
Nome do arquivo: RU_Web_TEW-703PI_703PIL(1.01).pdf
Data: 4/4/2017
Tamanho de arquivo: 1.77 MB
Nome do arquivo: EST_Web_TEW-703PI_703PIL(1.01).pdf
Data: 4/4/2017
Tamanho de arquivo: 1.75 MB
Nome do arquivo: UG_TEW-703PI_703PIL(V1.0R).pdf
Data: 4/4/2017
Tamanho de arquivo: 1.78 MB
JPEG Image
Tamanho de arquivo: : 260.36 KB
Data: : 4/4/2017
The TEW-703PI(L) is a wireless client. Your wireless router or access point defines your wireless network settings, including all security measures.
Please ensure you have taken into account all security measures employed by your wireless router or access point, such as Encryption, MAC Address Fil...
To connect at 150Mbps you must have a compatible and properly configured 150Mbps access point to connect to. For example, TRENDnet carries the following.
TEW-651BR 150Mbps Wireless N Home Router
https://www.TRENDnet.com/products/product-detail.asp?prod=230_TEW-651BR
TEW-650AP 150Mbps Wireless N ...
The TEW-703PI(L) is compatible on a computer running one of the following supported operating systems.
Windows: 7 (32/64-bit), Vista (32/64-bit), XP (32/64-bit)...
Note: The TEW-703PI & TEW-703PIL are wireless clients. Your existing wireless router or access point defines all of your wireless settings. This includes all security measures employed by your wireless router or access point, such as Encryption, MAC Address Filters and Access Control Lists. If you a...
Hardware |
Interface | - 32-Bit PCI 2.1 Bus
- Compatible with low profile desktop computers
|
---|
Standards | - IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
|
---|
LED Indicator | |
---|
Power Consumption | - Receive mode: 350mA (max.)
- Transmit mode: 400mA (max.)
|
---|
Supported OS | - Windows® 8.1, 8, 7, Vista and XP
|
---|
Dimensions | - 120 x 44 mm (4.7 x 1.75 in.)
|
---|
Weight | |
---|
Temperature | - Operating: 0° ~ 40° C (32° ~ 104° F)
- Storage: -10° ~ 70° C (14° ~ 158° F)
|
---|
Humidity | - 95% max. (non-condensing)
|
---|
Certifications | |
---|
Wireless |
Modulation | - DBPSK/DQPSK/CCK/OFDM (BPSK/QPSK/16-QAM/64-QAM)
|
---|
Antenna | - 1 x 2dBi dipole detachable antenna with Reverse SMA connector
|
---|
Frequency | |
---|
Data Rate (auto fallback) | - 802.11b: up to 11Mbps
- 802.11g: up to 54Mbps
- 802.11n: up to 150Mbps
|
---|
Output Power | - 802.11b: 15dBm (typical)
- 802.11g: 14dBm (typical)
- 802.11n : 12dBm (typical)
|
---|
Receiving Sensitivity | - 802.11b: -84dBm (typical) at 11Mbps
- 802.11g: -65dBm (typical) at 54Mbps
- 802.11n: -61dBm (typical) at 150Mbps
|
---|
Encryption | - 64/128-bit WEP (Hex & ASCII), WPA/WPA2 (TKIP/AES), WPA-PSK/WPA2-PSK
|
---|
Channels | |
---|
CONTEÚDO DA EMBALAGEM |
- TEW-703PIL
- CD-ROM (Utility & User's Guide)
- Multi-Language Quick Installation Guide
|
Todas as referências à velocidade são apenas para fins comparativos. As especificações, tamanho e formato do produto estão sujeitos a alterações sem aviso prévio, e a aparência real do produto pode ser diferente da descrita aqui.
