10 Gigabit PCIe Network Adapter

TEG-10GECTX (Version v3.0R)

Converts a PCIe slot into a 10G Ethernet Port
Supports 802.1Q VLAN Tagging
Includes standard and low-profile brackets
Windows® support
IEEE 802.3an and 802.3bz compliant
NDAA / TAA compliant (U.S. and Canada only)

DISCONTINUED PRODUCT

The TEG-10GECTX (Version v3.0R) has been discontinued. For a list of discontinued products, click here.

TRENDnet's 10 Gigabit PCIe Network Adapter, model TEG-10GECTX, converts a free PCI Express slot into a 10 Gigabit Ethernet port. The 10G PCIe card includes advanced features, such as jumbo frames and VLAN tagging support. The standard and low profile brackets included with the 10G PCIe card are compatible with Windows® desktop computer designs.

Illustration of a PCIe Network Adapter with two desktop computers connected to a network switch, highlighting the adapter’s role in providing network connectivity.

10G Port

10G PCIe card supports five speeds: 10Gbps, 5Gbps, 2.5Gbps, 1Gbps, and 100Mbps.

Illustration of a network tunnel labeled Jumbo Frame Up to 16KB with icons for music, film, and images, indicating data transfer.

Jumbo Frames

Sends larger packets, or jumbo frames (up to 16KB), for increased performance.

Three computers, including a desktop, server, and laptop, connected in a circular arrangement, representing compatibility with various operating systems.

Operating Systems

Compatible with Windows and Windows Server operating systems.

A control room setup with multiple computer monitors arranged on desks and several server racks in the background. The setup includes a highlighted paths labeled 10G, connecting the servers to the monitors. There is also a close-up of a network interface card labeled TEG-10GECTX, used to facilitate these high-speed connections.

10G Port

10G PCIe card supports five speeds: 10Gbps, 5Gbps, 2.5Gbps, 1Gbps, and 100Mbps

PCI Express

10GbE PCIe card converts a PCIe 3.0 x4 slot into a 10G Ethernet Port

2.5/5GBASE-T Support

2.5/5GBASE-T specification (802.3bz) supports 2.5G and 5G speeds over standard Cat5e cables at distances up to 100m

Jumbo Frame

Sends larger packets, or jumbo frames (up to 16KB), for increased performance

VLAN Support

IEEE 802.1Q tagged-based VLAN support

Brackets

Supports most installations with included standard and low-profile brackets

Operating Systems

Compatible with Windows and Windows Server operating systems

LED Indicators

LED indicators on the 10G PCIe card convey port status, link speed and activity

Standards	IEEE 802.3u IEEE 802.3ab IEEE 802.3bz 2.5G/5GBASE-T IEEE 802.3an 10GBASE-T IEEE 802.1Q
Hardware Interface	PCIe 3.0 x4 interface 1 x 10Gbps RJ-45 Ethernet port (Supported Speeds: 10Gbps / 5Gbps / 2.5Gbps / 1Gbps / 100Mbps) LED indicators
Cable Requirements	10GBASE-T (10Gbps): Cat6 twisted pair @ 55m / 180 ft. (max.) / Cat6A twisted pair @ 100 m / 328 ft. (max.) 5GBASE-T (5Gbps): Cat6 twisted pair @ 100m / 328 ft. (max.) 2.5GBASE-T (2.5Gbps): Cat5e twisted pair @ 100m / 328 ft. (max.) 1000BASE-T (1Gbps): Cat5e twisted pair @ 100m / 328 ft. (max.) 100BASE-TX (100Mbps): Cat5 twisted pair @ 100m / 328 ft. (max.)
Compatibility	Windows® 10, 8.1, 8 Windows® Server 2019, 2016, 2012, 2012 R2
Jumbo Frames	Up to 16KB
Special Features	10GBASE-T (10Gbps) & 2.5G/5GBASE-T (2.5Gbps/5Gbps) support for high speed network connectivity Windows Server support
Additional Support	802.1Q VLAN Tagging Receive-side scaling (RSS) Message Signaled Interrupts (MSI) IP, TCP, and UDP checksum offloading Minimize overhead with reduced host bus traffic and CPU utilization
Power	Max. consumption: 6.1W
Operating Temperature	0° – 70° C (32° – 158° F)
Operating Humidity	Max. 90% non-condensing
Certifications	CE FCC
Dimensions	120 x 63 x 17mm (4.7 x 2.5 x 0.7 in.)
Weight	76g (2.6 oz.)
Warranty	3 year

PACKAGE CONTENTS

TEG-10GECTX
Quick Installation Guide

All references to speed are for comparison purposes only. Product specifications, size, and shape are subject to change without notice, and actual product appearance may differ from that depicted herein.
