2-Port HDMI KVM Switch

TK-215i (Version v1.0R)

  • Control two computers with one set of console controls
  • Works with displays with an HDMI port
  • Full HD 1080p resolution
  • HDMI and 3.5 mm analog audio
  • Fully integrated cabling
  • Ergonomic computer toggle switch
  • No CD installation
  • USB Powered - No external power adapter
  • NDAA compliant
NDAA Compliant

TRENDnet's 2-Port HDMI KVM Switch, model TK-215i, controls two computers (with an available HDMI port) with one set of console controls. No driver installation required, simply plug in the integrated cables to share two computers with a full HD 1080p display. The TK-215i supports HDMI and 3.5 mm analog audio and features an ergonomic computer toggle switch.

The visual shows a setup for connecting two computers to a single console using various connectors and ports. On the left, Computer 1 is connected via an HDMI connector, optional analog microphone and speaker connectors, and a USB keyboard/mouse connector. In the center, the console features a computer toggle switch, microphone port, USB keyboard port, HDMI display port, USB mouse port, and speaker port. On the right, Computer 2 is connected similarly to Computer 1 with an HDMI connector, optional analog microphone and speaker connectors, and a USB keyboard/mouse connector. The setup includes labels and numbers to identify each component and connection, providing a clear guide for setting up the system.

Computers

Control up to 2 computers

1080p HD

Supports full HD 1080p (progressive 1920 x 1080 pixels) with a 60 Hz refresh rate

2-Way Audio

Full audio support through HDMI cable connections with optional 3.5 mm microphone and speaker jacks

Toggle Switch

Use the integrated 1.5 m (5 ft.) cable to position the toggle switch in the most ergonomic location

Console Connectors

Emulation Technology supports advanced USB keyboard and mouse designs

HDMI Display

HDMI 1.3 with HDCP support

Computer Ports

Requires free USB and HDMI ports from connected computer

Integrated Cables

All required cables are integrated

Switch Software

Windows®and Mac®based KVM switch software to define hot keys and create auto-scan intervals

Console Port on KVM
  • Keyboard: USB
  • Mouse: USB
  • Monitor: HDMI 1.3 (19-pin)
  • Speaker jack: 3.5 mm
  • Microphone jack: 3.5 mm
Computer Connections (up to 2)
  • Keyboard / mouse: USB 2.0 type A
  • Monitor: HDMI 1.3 (19-pin)
  • Speaker jack: 3.5 mm
  • Microphone jack: 3.5 mm
Monitor Resolution
  • 1920 x 1080 @ 60 Hz
Audio Support
  • 5.1 Audio support over HDMI cables
  • Analog audio over speaker and microphone jacks
LED
  • Computer 1 and Computer 2
Switching Control
  • One touch toggle switch
  • Keyboard hot key commands
  • KVM Switch Software
Supported OS
  • Windows® and Mac®
Operating Temperature
  • 0 – 40 °C (32 – 104 °F)
Operating Humidity
  • Max. 90 % non-condensing
Dimensions
  • Unit: 85 x 58 x 28 mm (3.3 x 2.3 x 1.1 in.)
  • Integrated Cable: 85 cm (3 ft.)
  • Toggle switch: 150 cm (5 ft.)
Weight
  • 350 g (12.3 oz.)
Warranty
  • 2 year limited
Certifications
  • CE
  • FCC

PACKAGE CONTENTS
  • TK-215i
  • Quick Installation Guide
  • CD-ROM (Utility & User's Guide)

*For optimal performance, we recommend using a wired keyboard and mouse. Please go to http:/www.trendnet.com/downloads to download the client switching software.


All references to speed are for comparison purposes only. Product specifications, size, and shape are subject to change without notice, and actual product appearance may differ from that depicted herein.
