N300 Wireless Gigabit Router
TEW-639GR (Version v2.0R)
- 14x the speed and 6x the range of wireless g
- Seamlessly stream video, download files, talk online and play games
- Features one-touch Wi-Fi Protected Setup (WPS) and manual wireless on / off switch
- Advanced wireless encryption and a firewall provides robust security
The N300 Wireless Gigabit Router offers unsurpassed wireless speed, coverage and reliability. Enjoy up to 14x the speed and 6x the coverage of a wireless g connection*.
Gigabit Wide Area Network and Local Area Network ports transfer your data fast. Wi-Fi certification ensures optimal wireless throughput signal strength and compatibility.
Advanced Multiple Input Multiple Output (MIMO) antenna technology eliminates wireless dead spots. Wireless encryption and a manual on/off wireless switch keeps your data safe. Wireless Protected Setup (WPS) integrates other WPS supported wireless adapters at the touch of a button. Seamlessly stream HD media, download files, surf and play games at wireless n speeds.
*Maximum wireless signal rates are referenced from IEEE 802.11 theoretical specifications. Actual data throughput and coverage will vary depending on interference, network traffic, building materials and other conditions.
- 4 x 10/100/1000Mbps Auto-MDIX LAN ports
- 1 x 10/100/1000Mbps WAN port (Internet)
- Gigabit LAN ports for high speed network connectivity
- Compatible with most popular cable/DSL Internet service providers using Dynamic/Static IP, PPPoE, PPTP and L2TP
- High-speed wireless data rates up to 300Mbps using an IEEE 802.11n connection
- 3 external antennas provide high-speed performance and expansive wireless coverage
- Advanced Firewall protection with Network Address Translation (NAT) and Stateful Packet Inspection (SPI)
- Access restriction with Internet Access Control; time scheduling and MAC filtering
- Built-in pre-configured virtual servers and Application Level Gateway services for special Internet applications
- Universal Plug and Play (UPnP) for auto discovery and support for device configuration of Internet applications
- Enable/disable wireless functionality with the WLAN on/off toggle switch and power switch.
- Multiple pass-through sessions for popular VPN applications (IPSec, L2TP and PPTP)
- Easy setup via Web browser using the latest versions of Internet Explorer, FireFox, Safari and Chrome
- One-touch wireless security setup using the Wi-Fi Protected Setup (WPS) button when connecting to a WPS supporting device
- Complete wireless security with WPA/WPA2, WPA/WPA2-PSK, and WEP
- Windows 95/98/NT/2000/XP/2003 Server/Vista/7, Linux and Mac OS supported
- 3- year limited warranty
*Maximum wireless signal rates are referenced from IEEE 802.11 theoretical specifications. Actual data throughput and coverage will vary depending on interference, network traffic, building materials and other conditions.
| Hardware | |
| Standards |
|
| WAN | 1 x 10/100/1000Mbps Auto-MDIX port (Internet) |
| LAN | 4 x 10/100/1000Mbps Auto-MDIX port |
| Wireless On/Off Switch | Turn on/off wireless LAN |
| WPS Button | Wi-Fi Protected Setup (WPS) automated wireless connection push button |
| Reset Button | Reset Router to Factory Defaults |
| Connection Type | Dynamic IP, Static (fixed) IP, PPPoE, PPTP, L2TP |
| NAT Firewall | 3K configurable NAT entries; restricted NAPT IP ranges, port ranges and schedule Port triggering for 24 special applications ALG support (enable/disable support) –RTP/RTSP, AOL, FTP, ICMP, WMP/MMS, NetMeeting, SIP |
| WDS | Enable/disable Wireless Distribution System support |
| UPnP | UPnP IGD 1.0 compliant |
| DMZ | DMZ host, 24 configurable Virtual Servers and Game Servers |
| DNS | Static or WAN assigned DNS servers; 4 verified services for DDNS |
| Internet Access Control | Time based Internet access; port range/service filtering; Internet domain restriction; 32 user defined schedules, 24 MAC address filter entries |
| LED Indicator | Power, LAN1~LAN4, WAN, WLAN, WPS |
| Power Switch | On/Off power switch |
| Power Adapter | 12V DC, 1A external power adapter |
| Power Consumption | 779mA |
| Dimension (L x W x H) | 150 x 163 x 26 mm (5.9 x 6.4 x 1.0 in) |
| Weight | 350g (0.8 lb) |
| Temperature |
|
| Humidity | Max. 90% (non-condensing) |
| Certifications | CE, FCC |
| Wireless | |
| Frequency | 2.412 ~ 2.472 GHz |
| Antenna | 3 x 4dBi fixed dipole antenna |
| Modulation | DBPSK/DQPSK/CCK/OFDM (BPSK/QPSK/16-QAM/64-QAM) |
| Data Rate |
|
| Security |
|
| Access Control | MAC Address Filter (Up to 24 entries) |
| Output Power |
|
| Receiving Sensitivity |
|
| Channels | 1~ 11 (FCC), 1~13 (ETSI) |
| |
| PACKAGE CONTENTS |
|
