8-Port Gigabit PoE+ Switch

TPE-TG80g (Version v3.1R)

  • 8 x Gigabit PoE+ ports
  • 123 W PoE power budget
  • 16 Gbps switching capacity
  • Sturdy metal switch
  • Plug and Play installation
  • Lifetime Warranty*

TRENDnet's 8-Port Gigabit PoE+ Switch, model TPE-TG80g, offers 8 x Gigabit PoE+ ports (30 Watts/port), a 16 Gbps switching capacity, and a PoE power budget of 123 Watts. Plug and Play this sturdy metal switch for reliable high speed PoE networking.

PoE+

A 123W PoE power budget supports up to eight Power over Ethernet devices.

Gigabit Ethernet

Eight gigabit PoE+ ports provide a 16Gbps switching capacity to support edge network installations.

Compact Design

With a compact and lightweight housing design, this switch is well-suited for desktop installations. Its fanless design is ideal for quiet environments that require silent operation.

PoE+

Supplies up to 30 Watts of PoE power per port with a 123 Watt power budget

Ports

8 x Gigabit PoE+ Ethernet ports

Switching Capacity

16 Gbps switching capacity

Jumbo Frame

Sends Jumbo Frames (up to 9 Kbytes) for increased performance

Energy Savings

Embedded GREENnet technology reduces power consumption

Housing

Rugged metal enclosure

LED Indicators

LED indicators convey port status

Standards
  • IEEE 802.1p QoS
  • IEEE 802.3
  • IEEE 802.3u
  • IEEE 802.3x
  • IEEE 802.3ab
  • IEEE 802.3af (15.4 Watts/port)
  • IEEE 802.3at (30 Watts/port)
  • IEEE 802.3az
Device Interface
  • 8 x Gigabit PoE/PoE+ ports
  • LED indicators
Data Transfer Rate
  • Ethernet: 10 Mbps (half duplex), 20 Mbps (full duplex)
  • Fast Ethernet: 100 Mbps (half duplex), 200 Mbps (full duplex)
  • Gigabit: 2000 Mbps (full duplex)
Performance
  • Data RAM Buffer: 128 KB
  • Switch Fabric: 16 Gbps
  • MAC Address Table: 8 K entries
  • Forwarding rate: 11.9 Mpps (64-byte packet size)
  • Jumbo Frame: 9 KB
Special Features
  • GREENnet energy saving technology
  • Input: 110-240 V AC, 50/60 Hz, 0.75 A
  • Output: 54 V DC, 2.77 A
  • Consumption: 5.3 Watts (Max. without PD)
PoE
  • PoE budget: 123 Watts
  • Pin 3, 6 for power+ and pin 1, 2 for power- (mode A)
Operating Temperature
  • 0 – 45 °C (32 - 113 °F)
Operating Humidity
  • Max. 90% non-condensing
Dimensions
  • 150 x 96 x 28 mm (5.9 x 3.8 x 1.1 in.)
Weight
  • 400 g (14 oz.)
Certifications
  • CE
  • FCC
Warranty

PACKAGE CONTENTS
  • TPE-TG80g
  • Quick Installation Guide
  • Power adapter (54 V DC, 2.77 A)

All references to speed are for comparison purposes only. Product specifications, size, and shape are subject to change without notice, and actual product appearance may differ from that depicted herein.
