SFP Dual Wavelength Single-Mode LC Module

TEG-MGBS40D3 (Version v4.0R)

  • Must pair with TEG-MGBS40D5 or other compatible module
  • LC Simplex connector-type
  • Dual wavelength fiber mode
  • Spans distances up to 40 km (24.9 miles)
  • Compatible with standard SFP slots
  • Lifetime Warranty*

The hot pluggable TEG-MGBS40D3 must be paired with the TEG-MGBS40D5 or other compatible module. This SFP Dual Wavelength Single Mode LC Type module spans distances of up to 40 kilometers (24.9 miles). The SFP interface is compatible with standard SFP slots and offers a 1000 Mbps-LX SFP interface.

  • Must pair with TEG-MGBS40D5 or other compatible module
  • Compliant with IEEE 802.3z Gigabit Ethernet
  • ANSI Fiber Channel compliant
  • Compliant with Small Form-Factor Pluggable (SFP) Multi-Source Agreement (MSA) ports
  • Supports data rate of up to 1.25 Gbps
  • Transmission distance of up to 40 km (24.9 miles)
  • Metal Enclosure with low Electromagnetic Interference (EMI) design
  • Simplex LC optical interface
  • Hot pluggable
  • Low power consumption
  • Lifetime Warranty*
HARDWARE
Standards
  • IEEE 802.3z Gigabit Ethernet
  • ANSI Fiber Channel compliant
  • Class 1 Laser
Interface
  • SFP MSA Compliant
  • Simplex LC optical interface
Power Consumption
  • Max. 0.8 Watts
Dimension
  • 57 x 13 x 12 mm (2.2 x 0.5 x 0.5 in.)
Weight
  • 18 g (0.6 oz.)
Temperature
  • Operating: 0°C ~ 70°C (32°F ~ 158°F)
  • Storage: -40°C ~ 85°C (-40°F ~ 185°F)
Humidity
  • Max. 85% (non-condensing)
Certifications
  • CE, FCC
Wavelength
  • TX: 1310 nm
  • RX: 1550 nm
Optical Output Power (dBm)
  • -3 ~ 3
Optical Input Power (dBm)
  • -25 ~ -3
Power Budget
  • -22
Distance
  • 40 km

PACKAGE CONTENTS
  • TEG-MGBS40D3
  • Quick Installation Guide

All references to speed are for comparison purposes only. Product specifications, size, and shape are subject to change without notice, and actual product appearance may differ from that depicted herein.
