10 Ft. USB to Serial Converter

TU-S910 (Version v3.2R)

  • Connect a RS-232 serial device, such as a switch, a modem, to a USB port on your computer
  • 10 ft. / 3m cable for easy installation
  • Supports USB 1.1, and compatible with USB 2.0 and USB 3.0 ports
  • Supports Windows® and Mac® operating systems
  • NDAA compliant
NDAA Compliant

TRENDnet’s 10 Ft. USB to Serial Converter Cable, model TU-S910, allows users to conveniently connect an RS-232 serial device, such as a switch, modem or printer, to a USB port on your desktop PC or laptop. The 10 ft. USB to serial adapter supports both Windows® and Mac® operating systems. Integrated cables provide setup flexibility and accommodates most installation scenarios.

A USB type A plug

USB

The USB to serial adapter is compatible with USB 1.1, 2.0 and 3.0 devices.

A network diagram using a USB to Serial Converter Cable for the network connection of a laptop.

RS-232 Serial Connector

Connect a RS-232 serial devices, such as switches, modems or printers, to standard USB ports on laptops and desktops.

10 Feet USB to Serial Converter Cable.

10 Ft. Flexible Cable

Integrated and flexible 3m (10 ft.) USB cable accommodates most installation scenarios.

Diagram illustrates connecting a laptop to a switch using a USB to RS-232 adapter cable, where the laptop's USB port connects to a 9-pin RS-232 male connector on the TU-S9 / TU-S910 adapter cable, then links to the switch's console port, enabling console access for network configuration and management

Easy Setup

Simple installation in seconds

Long & Flexible Cable

Integrated and flexible 3m (10 ft.) USB cable accommodates most installation scenarios

RS-232

Connect a RS-232 serial devices, such as switches, modems or printers, to standard USB ports on laptops and desktops.

USB

The USB to serial adapter is compatible with USB 1.1, 2.0 and 3.0 devices.

Operating Systems

The USB to serial adapter is compatible with Windows® and Mac® operating systems

Standards
  • USB 1.1
Interface
  • 1 x USB Type A
  • 1 x RS-232 (9-pin) male
  • Cable length: 3m (10 ft.)
Data Rate
  • Up to 6Mbps
Supported OS
  • Windows® 11, 10, 8.1, 8, 7
  • Mac OS® 10.11, 10.10, 10.9, 10.8, 10.7, 10.6
Operating Temperature
  • 0° – 40° C (32° – 104° F)
Operating Humidity
  • Max. 85% non-condensing
Power
  • USB powered
Power Consumption
  • 500mA (max.)
Dimensions
  • RS-232 connector: 65 x 35 x 10mm (2.55 x 1.4 x 0.4 in.)
  • Cable length: 3m (10 ft.)
Weight
  • 250g (8.82 oz.)
Warranty
  • 2 year
Certifications
  • CE
  • FCC

PACKAGE CONTENTS

  • TU-S910
  • Quick Installation Guide
  • CD-ROM (Drivers)

All references to speed are for comparison purposes only. Product specifications, size, and shape are subject to change without notice, and actual product appearance may differ from that depicted herein.
