10 dBi Wireless N300 Outdoor PoE Access Point

TEW-740APBO (Version v1.0R)

Wireless N300 building-to-building networking (2.4 GHz)
Supports Access Point (AP), Wireless Distribution System (WDS), Repeater, and Wireless Client modes
IP67 rated housing
Built in 10 dBi directional sector antenna

DISCONTINUED PRODUCT

The TEW-740APBO (Version v1.0R) has been discontinued. It has been replaced by the TEW-740APBO (Version v2.0R). For a list of discontinued products, click here.

TRENDnet's 10 dBi Outdoor PoE Access Point, model TEW-740APBO, provides Wireless N300 building-to-building connectivity. A variety of installation scenarios are facilitated with Access Point (AP), Wireless Distribution System (WDS), Repeater, and CPE + AP modes. The IP67 rated housing comes with wall and pole mounting hardware.

Point-to-Point

Wireless N300 building-to-building networking (2.4 GHz)

Illustration of a signal tower on the left emitting a wireless signal. The 10 dBi Wireless N300 Outdoor PoE Access Point TEW-740APBO is facing the signal tower. The access point is connected to a network switch, which has two laptops and two surveillance cameras connected to it.

Installation Flexibility

Supports Access Point (AP), Wireless Distribution System (WDS), Repeater, and Wireless Client modes

Two symbols indicating IP67 rating. The first symbol represents water resistance, and the second symbol indicates dust protection.

Outdoor Ready

IP67 rated housing

The illustration shows a TRENDnet outdoor networking device from three different angles with labeled features. These features include IP67 weather-rated, waterproof RJ-45 kit, mounting point, grounding point, Ethernet port, reset button, and LED indicators.

Performance

Multi-Mode Support

Supports Access Point (AP), Wireless Distribution System (WDS), Repeater, and Wireless Client modes

Wireless N300 (2.4 GHz)

Compliant with 802.11n/g/b technology (2.4 GHz) with data rates up to 300 Mbps*

Outdoor Rated

Durable enclosure with an IP67 outdoor weather rating

Directional Antenna

Built in 10 dBi directional antenna

Power over Ethernet (PoE)

Comes with a proprietary PoE injector, so that it can connect a regular non-PoE switch

Logs

Real time logs and statistics help troubleshooting

Encrypted Wireless

Support for wireless encryption of up to WPA2

Multiple SSIDs

Create up to eight additional SSIDs

Compatibility

Compatible with legacy wireless devices

Mounting Hardware

Pole and wall mount hardware included

Standards	IEEE 802.3 IEEE 802.3u IEEE 802.1d IEEE 802.1p IEEE 802.1Q IEEE 802.1X IEEE 802.11d IEEE 802.11e IEEE 802.11f IEEE 802.11h IEEE 802.11i IEEE 802.11b IEEE 802.11g IEEE 802.11n (2.4 GHz up to 300 Mbps)
Hardware Interface	1 x 10/100 Mbps port (proprietary PoE max. cable length 70 m) Reset button LED indicators
Special Features	IP67 weather rated 802.1Q VLAN assignment per SSID DDNS support for dyn.com, no-ip.com Schedule radio on / off time policy
Access Control	Wireless encryption: WEP, WPA / WPA2-PSK, WPA / WPA2-RADIUS Firewall (CPE Mode): NAT, Virtual Server, DMZ Host, PPTP / L2TP / IPsec VPN Passthrough Access Controls: MAC, IP Filter, Layer 2 Client Isolation, Per-SSID client limiting 802.1Q VLAN
QoS	WMM Diffserv (DSCP) / ToS 802.1p / CoS
Operation Modes	Access Point (AP) Wireless Distribution System (WDS) AP + WDS Repeater CPE + AP
SSID	Up to 8 SSIDs
Internet Connection Types (CPE mode)	Dynamic IP (DHCP) Static IP (Fixed) PPPoE (Dynamic IP / Static IP) PPTP (Dynamic IP / Static IP)
Management / Monitoring	Local / remote web based management (HTTP, HTTPS) Local / remote CLI based management (Telnet, SSH) SNMP v1 / v2c / v3 SNMP Trap MIB II Upgrade firmware Backup / restore configuration Event logging Reboot Restore to factory defaults Ping test Ping Watchdog
Routing	Static Dynamic (RIP v1/2, OSPF)
Frequency	FCC: 2.412 - 2.462 GHz ETSI: 2.412 – 2.472 GHz IC: 2.412 - 2.462 GHz
Wireless Channels	FCC: 1-11 ETSI: 1-13
Modulation	802.11b: DBPK, DQPSK, CCK with DSSS 802.11g/n: BPSK, QPSK, 16-QAM, 64-QAM with OFDM
Media Access Protocol	CSMA/CA with ACK
Antenna Gain	10 dBi internal sector antenna
Wireless Output Power / Receiving Sensitivity	802.11b: FCC / ETSI: FCC: 28 dBm (max.), ETSI: 10.6 dBm (max.), IC: 28 dBm (max.) / -88 dBm (typical) @ 11 Mbps 802.11g: FCC / ETSI: FCC: 27 dBm (max.), ETSI: 10.7 dBm (max.), IC: 27 dBm (max.) / - 74 dBm (typical) @ 54 Mbps 802.11n: FCC / ETSI: FCC: 28 dBm (max.), ETSI: 10.7 dBm (max.), IC: 28 dBm (max.) / - 69 dBm (typical) @ 300 Mbps
Power	Input: 100 – 220 V, 50 - 60 Hz, 0.6 A Output: 48v / 0.5A Consumption: 22 Watts Max.
Operating Temperature	-30 - 60° C (-22 - 140° F)
Operating Humidity	Max. 99% non-condensing
Certifications	CE FCC
Dimensions	218 x 125 x 54 mm (8.6 x 4.9 x 2.1 in.)
Weight	424 g (0.9 lbs.)
Warranty	3 year limited

PACKAGE CONTENTS

TEW-740APBO
CD-ROM (Utility & User's Guide)
Quick Installation Guide
Power adapter (48 V DC, 0.5 A)
Proprietary PoE injector
Waterproof RJ-45 kit
Grounding wire
Mounting hardware

* Effective wireless coverage may vary depending on the wireless device's output power, antenna gain, antenna alignment, receiving sensitivity, and radio interference. Additionally environmental factors such as weather conditions, physical obstacles, and other considerations may affect performance. For optimal results, we recommended consulting a professional installer for site survey, safety precautions, and proper installation.

All references to speed are for comparison purposes only. Product specifications, size, and shape are subject to change without notice, and actual product appearance may differ from that depicted herein.
