1000Base-LX Industrial SFP Single-Mode LC Module (10km)

TI-MGBS10 (Version v1.1R)

  • Compliant with IEEE 802.3z Gigabit Ethernet
  • ANSI Fiber Channel compliant
  • Small Form-Factor Pluggable (SFP) and Multi-Source Agreement (MSA) compliant
  • Wide operating temperature range of -40°– 85 °C (-40° – 185 °F)
  • Supports data rates of up to 1.25Gbps
  • Transmission distance of up to 10km (6.2 miles)
  • Low Electromagnetic Interference (EMI) design
  • Supports 1310nm single-mode network transmissions
  • Duplex LC optical interface
  • Low power consumption
  • NDAA / TAA compliant
  • Lifetime Warranty*
NDAA/TAA Compliant

Price: $41.79
Quantity:
Wishlist

The 1000Base-LX Industrial SFP Single-Mode LC Module, model TI-MGBS10, is designed to operate within a wide temperature range and is well suited for industrial environments. This SFP module works with standard SFP slots found on industrial switches and fiber converters. The TI-MGBS10 is compatible with Duplex LC fiber connector types and supports gigabit single-mode fiber connections at distances of up to 10 kilometers (6.2 miles).

A schematic representation of long-distance fiber networking for industrial, manufacturing, and corporate/education campus applications. The image features two switches connected together with a fiber connection. The bottom switch is connected to a dome camera, a wireless access point, and a bullet camera.

Fiber Applications

Long distance fiber networking for industrial, manufacturing, and corporate / education campus applications.

Illustration of a fiber optic cable transmitting data over long distances, with light visually represented traveling through the cable., labeled as 10km (6.2 miles.).

Fiber Mode / Distance

Single-Mode transceiver spans distances up to 10km (6.2 miles) and supports up to 1.25Gbps.

A diagram of a sfp module connecting into a network switch.

Compatibility

Hot-pluggable with a MSA compliant SFP slot and compatible with fiber cables with LC-type duplex connectors.

Hot-Pluggable SFP

Hot-pluggable SFP transceiver compatible with a MSA compliant SFP slot

Fiber Wavelength

Compatible with single-mode 1310nm transmissions

Fiber Distance

Supports networking for distances up to 10km (6.2 miles)

Fiber Interface

LC-type duplex connector

Operating Temperature

Rated for an operating temperature range of -40°– 85 °C (-40° – 185 °F)

Standards
  • IEEE 802.3
  • IEEE 802.3u
  • IEEE 802.3z
Device Interface
  • SFP MSA Compliant
  • LC duplex connector
Data Transfer Rate
  • 1.25Gbps
Wavelength
  • 1310nm
Optical Output Power
  • -9 ~ -3 dBm
Distance
  • 10km (6.2 mi.)
Special Features
  • Hot pluggable
  • Metal enclosure
Sensitivity
  • -23 dBm
Power
  • Consumption: 1W
Operating Temperature
  • -40 – 85 °C (-40 – 185 °F)
Operating Humidity
  • Max. 95% non-condensing
Dimensions
  • 57 x 13 x 8.5 mm (2.2 x 0.5 x 0.3 in.)
Weight
  • 19 g (0.67 oz.)
Certifications
  • CE
  • FCC
Warranty
PACKAGE CONTENTS
  • TI-MGBS10
  • Quick Installation Guide

All references to speed are for comparison purposes only. Product specifications, size, and shape are subject to change without notice, and actual product appearance may differ from that depicted herein.
