8-Channel HD PoE+ NVR with 2 TB HDD (Certified Refurbished)

RB-TV-NVR208D2 (Version v1.0R)

Standalone 8-channel PoE+ network video recorder
Plug and play up to 8 TRENDnet PoE cameras*
Concurrent 1080p HD video recording for all channels
Preinstalled 2 TB HDD provides one week of continuous 1080p video recording***
Two 3.5” SATA II bays support up to a 12 TB of storage (6 TB max. per bay, additional HDDs sold separately)
Advanced video playback
Rack mountable
PoE power budget: 120 W
Supports ONVIF compliant network camera

TRENDnet's standalone 8-channel HD PoE+ NVR, model TV-NVR208D2, offers a comprehensive rack mountable camera management solution. This NVR includes a preinstalled 2 TB hard drive and connects up to eight cameras*. Install up to 12 terabytes of storage (additional hard drives sold separately) to record four weeks of continuous video from eight HD cameras**. The TV-NVR208D2 features advanced video playback and free iOS^® / Android^™ apps available.

Standalone HD NVR

This standalone 1080p HD NVR includes a preinstalled 2 TB hard drive and supports a total storage capacity of up to 12 TB and powers up to eight PoE network cameras-HDDs, cameras, and display sold separately.

Plug-and-Play Installation

The NVR auto-recognizes and powers TRENDnet PoE cameras* – simply connect compatible TRENDnet PoE cameras and start recording surveillance video.

Intuitive Interface

Users will find the management interface intuitive and easy to use – quickly navigate live view preferences, recording schedules, and advanced playback options.

PoE+ Ports

Plug and play TRENDnet PoE network cameras* to the eight PoE+ ports with a total power budget of 120 W

Storage

Two 3.5” SATA II bays support up to 12 TB of total storage (2 TB HDD Included, 6 TB max. per bay)

Network Uplink Port

Gigabit Ethernet network uplink port

Display Interface

HDMI and VGA interfaces

Audio Ports

Audio in and out ports

USB Ports

One USB port for the included mouse and one for configuration backup

Mouse Included

Supports mouse and keyboard (keyboard sold separately)

Rack Mount

Rack mount hardware included

Mobile App

See live video on a mobile device with the free iOS® and Android™apps

Remote Access

Access the NVR over the internet

Camera Setup

Auto-recognizes TRENDnet cameras* and works with most PoE network cameras

Live View

Multiple camera viewing options with auto-scan function

Camera Management

For each camera, manage on-screen display (OSD), image settings, PTZ functionality, motion detection, privacy masks, tamper detection, and video loss

Video Recording

Max. resolution for all cameras concurrently: Full HD 1080p video at 30 fps in H.264 compression
Max. for a single camera: 6 MP resolution in H.264 compression

Recording Time

One week of continuous recording per camera with preinstalled 2 TB HDD and 8 x 1080p cameras at 30 fps (medium VBR)
Four weeks of continuous recording per camera with 12 TB of storage (HDDs sold separately) and 8 x 1080p cameras at 30 fps (medium VBR)

Scheduled Recording

Create weekly continuous and motion detection recording schedules for each camera with video overwrite when storage is full

Advanced Playback

Advanced archived video playback with a quick reference timeline and calendar

Video Export

Quickly export and archive recorded video

Dynamic DNS Support

Support for dyn.com and NO-IP.com

IPv6

IPv6 support

ONVIF

Supports ONVIF compliant network camera

Video Output	HDMI / VGA Resolution: 1920 × 1080P / 60Hz 1600 × 1200P / 60Hz 1280 × 1024 / 60Hz 1280 × 720 / 60Hz 1024 × 768 / 60Hz
Audio	Line-in with RCA connector (2.0 Vp-p, 1 kΩ) Line-out with RCA connector
Recording	8-channel simultaneous recording up to 1080p 30 fps 2 SATA interface for HDD or SSD up to 6 TB storage each
Playback	Playback resolution: 5MP, 3MP, 1080p, UXGA, 720p, VGA, 4CIF, DCIF, 2CIF, CIF, QCIF
Hardware Standards	IEEE 802.3 IEEE 802.3u IEEE 802.3x IEEE 802.3ab IEEE 802.3af IEEE 802.3at
Device Interface	1 x Gigabit network port 8 x 10/100 PoE+ camera network ports 1 x 2 TB HDD 1 x USB 2.0, 1 x USB 3.0 HDMI port VGA port Analog audio in / out port Power port LED indicators (Power, Storage, and Network)
PoE Ports	PoE 802.3at (max. 30 W per port) Total PoE power budget: 120 W Plug and play with TRENDnet PoE cameras*
Network Protocol	IPv4, IPv6, UDP, TCP, ICMP, SSL, TLS, ONVIF v2.2 DHCP, NTP, DNS, DDNS, SMTP, FTP, SNMP v2 HTTP, UPnP, RTSP, RTP, RTCP
Operating Temperature	-10 ~ 55 °C (14 ~ 131 °F)
Operating Humidity	Max. 90% non-condensing
Certifications	CE FCC UL 60950
Dimensions	380 x 310 x 45 mm (15 x 11 x 1.8 in.)
Weight	3.3 kg (7.3 lb.)
Power	Input: 100 – 240 V AC, 50/60 Hz Power consumption: Main board: 10 W max. Fully loaded with HDD and PoE: 150 Watts max.
Management Interface	Live view: Simultaneous 3x3, 1+7, 1+5, 2x2 views or auto switch single view Scheduled recording: continuous and motion detection with optional holiday exceptions. Supporting camera configuration through NVR*: On Screen Display, display settings: brightness, contrast, saturation, PTZ, motion detection setting, video tamper, and video loss. Holiday scheduling for custom recording schedules during observed holidays Advanced playback: playback multiple channels simultaneously and search video recordings with special event or tag Video export: tag, cut, and export video clips HDD: Encoded disk formatting, S.M.A.R.T. disk health monitoring and testing, bad sector detection, storage quota allocation to each video channel, recycle old recordings or send disk full warning to administrator by email USB external storage: firmware upgrade, import / export configuration file and logs, export recorded video files, search and playback videos directly from external storage Local live view settings: define screen layout and channel viewing sequence Alert messages: storage full, storage error, network disconnected, IP conflict, illegal login, and recording exceptions, and PoE power overload. Supported dynamic DNS services: Dyn.com and NO-IP.com Management Setting: maximum 32 user accounts Traffic chart and statistics for network management
TRENDnet IP View App	Free iOS^® and Android^™ app View your NVR video on your mobile device Take snapshots Zoom
Warranty	90-day

PACKAGE CONTENTS

TV-NVR208
1 x 2TB HDD
CD-ROM (Utility & User's Guide)
Power cord (1.8 m / 6 ft.)
Network cable (1.8 m / 6 ft.)
HDMI cable (1.8 m / 6 ft.)
Optical mouse
IR Remote Control
SATA data cables / power cables
Quick Installation Guide
Rack mount hardware

*See list of compatible cameras http://www.trendnet.com/products/nvr-solutions
** Four weeks of continuous recording 8 cameras in 1080p resolution at 30 fps (medium VBR) with 12 TB of storage (HDDs not included)
*** One week of continuous recording per camera with preinstalled 2 TB HDD and 8 x 1080p cameras at 30 fps (medium VBR)

All references to speed are for comparison purposes only. Product specifications, size, and shape are subject to change without notice, and actual product appearance may differ from that depicted herein.
