Powerline 500 AV Adapter with Built-In Outlet
TPL-402E (Version v1.0R)
- Up to 500 Mbps networking speeds from electrical outlet
- Never lose an electrical outlet with the built in socket
- Advanced noise filter boosts performance
- Power Save mode reduces electrical consumption by 80%
- Use one to transmit and up to 15 TPL-402Es to receive a networked signal
DISCONTINUED PRODUCT
The TPL-402E (Version v1.0R) has been discontinued. It has been replaced by the TPL-423E (Version v1.0R). For a list of discontinued products, click here.Utility
Release Date: 9/2013
Utility Version: v7.1 Build 0101
WinPcap Version: v4.1.3
OS Compatibility: Windows® 8.1 (32/64-bit), 8 (32/64-bit), Windows 7 (32/64-bit), Vista (32/64-bit), XP (32/64-bit)
Notes:
- Added compatibility for Windows® 8/8.1
*Prerequisite: Requires Microsoft® .NET Framework 2.0. Please refer to the Microsoft download center for details on downloading and installing .NET Framework 2.0
***To start the installation, double click the file "Installer_CD.bat***
Filename: Utility_Powerline(v7.1.0101).zip
SHA-1 Checksum: 764C84BB70A7ED416094EBF79A2E91F70CB97023
Date: 7/28/2017
File Size: 6.52 MB
Firmware
Firmware Version: 5.2.4.03
Release Date: 8/2014
Note:
- Fixed - Interoperability issues between other powerline adapters
- Improved - Connection Stability and Performance
Filename: FW_TPL-402E_v1(5.2.4.03).zip
SHA-1 Checksum: F6BBD893CE14AF097E627A90938B2F2013C130D1
Date: 7/28/2017
File Size: 7.51 MB
Datasheet
Filename: EN_spec_TPL-402E(V1.0R).pdf
Date: 5/22/2014
File Size: 917.84 KB
Filename: FR_spec_TPL-402E(V1.0R).pdf
Date: 5/22/2014
File Size: 943.60 KB
Filename: GE_spec_TPL-402E(V1.0R).pdf
Date: 5/22/2014
File Size: 928.26 KB
Filename: SP_spec_TPL-402E(V1.0R).pdf
Date: 5/22/2014
File Size: 939.82 KB
Filename: RU_spec_TPL-402E(V1.0R).pdf
Date: 5/22/2014
File Size: 915.50 KB
Filename: IT_spec_TPL-402E(V1.0R).pdf
Date: 5/22/2014
File Size: 938.63 KB
Quick Installation Guide
Filename: EN_Web_TPL-402E_TPL-402E2K(1.01).pdf
Date: 11/15/2012
File Size: 2.28 MB
Filename: FR_Web_TPL-402E_TPL-402E2K(1.01).pdf
Date: 11/15/2012
File Size: 2.26 MB
Filename: GE_Web_TPL-402E_TPL-402E2K(1.01).pdf
Date: 11/15/2012
File Size: 1.78 MB
Filename: SP_Web_TPL-402E_TPL-402E2K(1.01).pdf
Date: 11/15/2012
File Size: 1.77 MB
Filename: RU_Web_TPL-402E_TPL-402E2K(1.01).pdf
Date: 11/15/2012
File Size: 2.77 MB
Filename: EST_Web_Web_TPL-402E_TPL-402E2K(1.01).pdf
Date: 11/15/2012
File Size: 1.51 MB
User's Guide
Product Images
If the PL LED is red indicating good quality only, try plugging the TPL-402E into another available wall power outlet to check if you can obtain better connection quality.
Use a pin or paperclip and push and hold the Reset button for 1 second on each TPL-402E powerline adapter. All LEDs will turn o...
You can have a total of 64 units. Only 16 units are recommended on a single network. Additional adapters may decrease performance.
Please reference the items below if you continue to experience difficulty with installing and using your TPL-402E 500Mbps Powerline AV Adapter.
Try power cycling th...
Power (PWR)
Off – Power Off
Solid Green – Power On
Powerline (PL)
Off – No powerline link
Solid Green – Successful powerline link (Connection quality: Best)
Blinking Green – Activity
Solid Amber – Successful powerline link (Connection quality: Better)
Blinking Amber – Activity
Solid R...
Reset the TPL-402E by pressing and holding in the reset button for approximately 10 seconds. The default network ID is HomePlugAV. You can synchronize the power line devices again by pressing and holding the sync button for 3 seconds on each unit. ...
Ensure you do not have the TPL-402E units connected to surge protectors or to any outlet with appliances. Please also ensure the units are connected to outlets within the same circuit breaker box. Reset the units and ensure they are configured with the same Network ID or use the sync button to conne...
