N150 Wireless Home Router

TEW-711BR   (Version v1.0R)

   Select Another Version
  • Stream video, download files, talk online and play games wirelessly
  • Connect computers with one-touch Wi-Fi Protected Setup (WPS)
  • Up to 50% energy savings with GREENnet technology

DISCONTINUED PRODUCT

The TEW-711BR (Version v1.0R) has been discontinued. It has been replaced by the TEW-831DR (Version v1.0R). For a list of discontinued products, click here.

Firmware

Firmware
DO NOT upgrade firmware on any TRENDnet product using wireless connection.
Firmware upgrade over wireless connection may damage the product. Please perform firmware upgrade with "wired" network connection only

Firmware Version: 1.03b01
Release Date: 6/2015
Note:

  1. Fixed UPnP miniigd security vulnerability issue.

Filename: FW_TEW-711BR_v1(1.03b01).zip
SHA-1 Checksum: D13148C90813829C29FD4CC643E9153AB56A9673
Date: 7/28/2017
File Size: 3.22 MB
Download

Datasheet

Datasheet (English)
Filename: EN_spec_TEW-711BR(V1.0R).pdf
Date: 11/12/2012
File Size: 637.10 KB
Download Email
Datasheet (Français)
Filename: FR_spec_TEW-711BR(V1.0R).pdf
Date: 11/12/2012
File Size: 631.34 KB
Download Email
Datasheet (Deutsch)
Filename: GE_spec_TEW-711BR(V1.0R).pdf
Date: 11/12/2012
File Size: 626.81 KB
Download Email
Datasheet (Español)
Filename: SP_spec_TEW-711BR(V1.0R).pdf
Date: 11/12/2012
File Size: 678.01 KB
Download Email
Datasheet (Pусский)
Filename: RU_spec_TEW-711BR(V1.0R).pdf
Date: 2/6/2014
File Size: 902.24 KB
Download Email
Datasheet (Italiano)
Filename: IT_spec_TEW-711BR(V1.0R).pdf
Date: 11/12/2012
File Size: 675.64 KB
Download Email

Quick Installation Guide

Quick Installation Guide (English)
Filename: EN_Web_TEW-711BR(1.02).pdf
Date: 11/12/2012
File Size: 1.69 MB
Download
Quick Installation Guide (Français)
Filename: FR_Web_TEW-711BR(1.02).pdf
Date: 11/12/2012
File Size: 1.71 MB
Download
Quick Installation Guide (Deutsch)
Filename: GE_Web_TEW-711BR(1.02).pdf
Date: 11/12/2012
File Size: 1.24 MB
Download
Quick Installation Guide (Português)
Filename: PO_Web_TEW-711BR(1.02).pdf
Date: 11/12/2012
File Size: 1.22 MB
Download
Quick Installation Guide (Español)
Filename: SP_Web_TEW-711BR(1.02).pdf
Date: 11/12/2012
File Size: 1.69 MB
Download
Quick Installation Guide (Pусский)
Filename: RU_Web_TEW-711BR(1.02).pdf
Date: 11/12/2012
File Size: 1.78 MB
Download
Quick Installation Guide (Eesti)
Filename: EST_Web_TEW-711BR(1.02).pdf
Date: 11/12/2012
File Size: 1.22 MB
Download
Quick Installation Guide (Polski)
Filename: POL_Web_TEW-711BR(V1.1R).pdf
Date: 4/18/2013
File Size: 2.46 MB
Download
Quick Installation Guide (Român)
Filename: RO_Web_TEW-711BR(V1.1R).pdf
Date: 4/18/2013
File Size: 2.86 MB
Download
Quick Installation Guide (Nederlands)
Filename: NL_Web_TEW-711BR(V1.1R).pdf
Date: 4/18/2013
File Size: 2.26 MB
Download
Quick Installation Guide (Magyar)
Filename: HU_Web_TEW-711BR(V1.1R).pdf
Date: 4/18/2013
File Size: 2.45 MB
Download
Quick Installation Guide (български)
Filename: BL_Web_TEW-711BR(V1.1R).pdf
Date: 4/18/2013
File Size: 2.30 MB
Download

User's Guide

User's Guide
Filename: UG_TEW-711BR(v1).pdf
Date: 4/30/2014
File Size: 1.85 MB
Download

Product Images

JPEG Image
File Size: : 225.52 KB
Date: : 9/28/2011
Download
JPEG Image
File Size: : 213.75 KB
Date: : 9/28/2011
Download
JPEG Image
File Size: : 184.85 KB
Date: : 9/28/2011
Download
JPEG Image
File Size: : 253.88 KB
Date: : 9/28/2011
Download
TIFF Image
File Size: : 2.46 MB
Date: : 9/28/2011
Download
TIFF Image
File Size: : 2.48 MB
Date: : 9/28/2011
Download
TIFF Image
File Size: : 2.26 MB
Date: : 9/28/2011
Download
TIFF Image
File Size: : 3.51 MB
Date: : 9/28/2011
Download
ROHS compliant WEEE crossed-out bin symbol.
How do I secure my wireless network?
Log in to the TEW-711BR by entering https://192.168.10.1 into the address line of your browser. The default User Name and Password are both admin. Click Wireless and then Security. Select the highest form of security supported by your wireless computers and network appliances. Note: For 802.11...
How do I setup my wireless network?
Connect a computer to one of the LAN ports on the TEW-711BR. Log in to it by entering https://TEW-711BR or https://192.168.10.1 into the address line of your browser. The username is admin. For added security, the router is preconfigured with a unique password. You can find the password on a stic...
How do I log into the router and configure it?
Connect a computer to one of the LAN ports on the TEW-711BR. Log in to it by entering https://TEW-711BR or https://192.168.10.1 into the address line of your browser. The username is admin. For added security, the router is preconfigured with a unique password. You can find the password on a stic...
How do I forward ports?
Connect a computer to one of the LAN ports on the TEW-711BR. Log in to it by enteringhttps://TEW-711BR orhttps://192.168.10.1 into the address line of your browser. The username is admin. For added security, the router is preconfigured with a unique password. You can find the password on a sticke...
How do I reset the router to factory default settings?
Press and hold in the reset button on the back of the router for approximately 15 seconds while the power is on. The default values are as follows. IP Address: 192.168.10.1 Username: admin Password: admin ...
When I attempt to connect to the router I am prompted for a PIN. Where is this located?
Connect a computer to one of the LAN ports on the TEW-711BR. Log in to it by entering https://TEW-711BR or https://192.168.10.1 into the address line of your browser. The username is admin. For added security, the router is preconfigured with a unique password. You can find the password on a stic...
What is the default username and password on the router?
The default User Name and password are both admin.
Hardware
Standards
  • IEEE 802.3 (10BASE-T), IEEE 802.3u (100BASE-TX), IEEE 802.11b,
  • IEEE 802.11g, Based on IEEE 802.11n technology, IEEE 802.3az
WAN
  • 1 x 10/100Mbps Auto-MDIX WAN port (Internet)
LAN
  • 4 x 10/100Mbps Auto-MDIX LAN ports
WPS Button
  • Enables Wi-Fi Protected Setup (WPS) function (Hold for 3 seconds)
Power Switch
  • On/Off power switch
Connection Type
  • Dynamic IP, Static (fixed) IP, PPPoE, PPTP, L2TP
Supported Web Browsers
  • Internet Explorer 6.0 or above, Firefox 2.0 or above, Chrome, Opera, Safari
Internet Access Control
  • MAC Address Filter, Domain/URL Filter, Protocol/IP Filter, Virtual Server, DMZ host, UPnP, PPTP/L2TP/IPsec VPN pass through
Management / Monitoring
  • Local/remote configuration, upgrade firmware, Backup/Restore configuration via Web browser, Internal System Log, Syslog, E-Mail Logging, SNMPv1/v2c, Ping Test Tool, Dynamic DNS
Routing
  • Static and Dynamic RIPv1/2
LED Indicators
  • Power, Status, LAN1 - LAN4, WAN, WLAN
Power Adapter
  • 5V DC, 1A external power adapter
Power Consumption
  • 2.8 Watts (max)
Dimensions (L x W x H)
  • 158 x 109 x 34 mm (6.2 x 4.3 x 1.3 in)
Weight
  • 204 g (7.2 oz)
Temperature
  • Operating: 0° ~ 40°C (32° ~ 104°F)
  • Storage: -10°C ~ 70°C (-14° ~ 158°F)
Humidity
  • Max. 95% (non-condensing)
Certifications
  • CE, FCC
Wireless
Frequency
  • 2.412 ~ 2.484 GHz ISM band
Antenna
  • 1 x 2dBi fixed dipole antenna
Modulation
  • 802.11b: CCK (11 and 5.5Mbps), DQPSK (2Mbps), DBPSK (1Mbps)
  • 802.11g: OFDM with BPSK, QPSK and 16/64-QAM
  • 802.11n: BPSK, QPSK, 16QAM, 64QAM with OFDM
Media Access Protocol
  • CSMA/CA with ACK
Data Rate
  • 802.11b: up to 11Mbps
  • 802.11g: up to 54Mbps
  • 802.11n: up to 150Mbps
Output Power
  • 802.11b: 15dBm (typical) @ 11Mbps
  • 802.11g: 15dBm (typical) @ 54Mbps
  • 802.11n: 13dBm (typical) @ 150Mbps
Receiving Sensitivity
  • 802.11b: -85dBm (typical) @ 11Mbps
  • 802.11g: -68dBm (typical) @ 54Mbps
  • 802.11n: -62dBm (typical) @ 150Mbps
Encryption
  • 64/128-bit WEP (HEX/ASCII), WPA /WPA2-PSK, WPA/WPA2-RADIUS
Channels
  • 1-11 (FCC), 1-13 (ETSI)

PACKAGE CONTENTS
  • TEW-711BR
  • Multi-Language Quick Installation Guide
  • CD-ROM (User's Guide)
  • Network cable (1.5 m / 5 ft.)
  • Power adapter (5V DC, 1A)

All references to speed are for comparison purposes only. Product specifications, size, and shape are subject to change without notice, and actual product appearance may differ from that depicted herein.
