N300 PoE Access Point

TEW-755AP   (Version v1.0R)

  • WiFi N300 PoE access point
  • Access Point, Client, WDS AP, WDS Bridge, WDS Station, and Repeater modes
  • Included software utility aides WiFi network management
  • Gigabit PoE LAN port
  • Off-white low profile housing blends into the environment
  • Mounting plate
  • NDAA / TAA compliant (U.S. and Canada only)
NDAA/TAA Compliant

Utility

Utility
Utility Version: 1.60
Release Date: 10/2018
OS Compatibility: Windows® 10, 8.1, 8, 7, Vista, XP, Windows® 2003/2008 Server

Note:
  • Fixed issue uploading AP configuration files
  • Fixed issue upgrading firmware 1.07B07 to 1.08B04 on model TEW-821DAP H/W:v1.XR
  • Added support for TEW-826DAP H/W: v1.XR

*Any previous AP utility versions must be completely uninstalled before installing version 1.60 or above.*


Filename: Utility_APUtility(v1.60).zip
SHA-1 Checksum: 3B6FE7BEEFF0767B0E3A6DB74A16EDADC4813328
Date: 10/10/2018
File Size: 24.79 MB
Download

Firmware

Firmware

** APs must be upgraded to firmware version 1.13B01 first before upgrading to version 2.02B01 or above. APs must be upgraded to firmware version 1.07B07 first before upgrading to version 1.08B04 or above. APs currently running firmware version 1.00BXX must be upgraded to version 1.02BXX first before upgrading to version 1.07B07.(Firmware 1.13B01, 1.07B07, and 1.02BXX are included in the download for Firmware version 2.02B01)

Firmware Version: 2.03B02
Release Date: 05/2023
Note:
  • Update Open SSL
  • Remove Bandsteering

Filename: TEW-755AP_FW203B02.zip
SHA-1 Checksum: 3D358031633E3E917EB892AD4E8F8F11E0F8A013
Date: 5/19/2023
File Size: 14.73 MB
Download
Firmware

*(Firmware version 1.07B07 and above) TRENDnet AP models TEW-755AP(H/W:v1.XR) / TEW-821DAP(H/W:v1.XR) / TEW-825DAP(v1.XR) can now use the same firmware file image to upgrade any of the 3 models. (ex. 755AP FW: 1.07B07 firmware file can be used to upgrade TEW-821DAP/TEW-825DAP and vice versa)*

**Prerequisites: APs must be upgraded to firmware version 1.13B01 first before upgrading to version 2.02B01 or above.APs must be upgraded to firmware version 1.07B07 first before upgrading to version 1.08B04 or above. APs currently running firmware version 1.00BXX must be upgraded to version 1.02BXX first before upgrading to version 1.07B07.(Firmware 1.13B01, 1.07B07, and 1.02BXX are included in this download)**

Firmware Version: 2.02B01
Release Date: 03/2023
Note:
  • Updated GUI
  • Fixed security vulnerabilities

Filename: FW_TEW-755AP_v1(2.02B01).zip
SHA-1 Checksum: 78D64E8C82035BBF4101C8A0979C6738F6FD8541
Date: 4/3/2023
File Size: 49.90 MB
Download

Other

MIB
MIB Version: 1.00.01
Release Date: 6/2017
  • Initial Release

Filename: MIB_TEW-755AP_v1(1.00.01).zip
Date: 7/25/2017
File Size: 9.08 KB
Download

Datasheet

Datasheet (English)
Filename: EN_datasheet_TEW-755AP(v1.0R).pdf
Date: 10/5/2017
File Size: 5.98 MB
Download Email
Datasheet (Français)
Filename: FR_datasheet_TEW-755AP(v1.0R).pdf
Date: 10/5/2017
File Size: 6.04 MB
Download Email
Datasheet (Deutsch)
Filename: GE_datasheet_TEW-755AP(v1.0R).pdf
Date: 10/5/2017
File Size: 6.10 MB
Download Email
Datasheet (Português)
Filename: PO_datasheet_TEW-755AP(v1.0R).pdf
Date: 10/5/2017
File Size: 6.09 MB
Download Email
Datasheet (Español)
Filename: SP_datasheet_TEW-755AP(v1.0R).pdf
Date: 10/5/2017
File Size: 6.11 MB
Download Email
Datasheet (Italiano)
Filename: IT_datasheet_TEW-755AP(v1.0R).pdf
Date: 10/5/2017
File Size: 6.12 MB
Download Email

Quick Installation Guide

Quick Installation Guide (English)
Filename: EN_Web_TEW-755AP(V1.0R).pdf
Date: 2/27/2018
File Size: 1.65 MB
Download
Quick Installation Guide (Français)
Filename: FR_Web_TEW-755AP(V1.0R).pdf
Date: 2/27/2018
File Size: 1.66 MB
Download
Quick Installation Guide (Deutsch)
Filename: GE_Web_TEW-755AP(V1.0R).pdf
Date: 2/27/2018
File Size: 1.50 MB
Download
Quick Installation Guide (Português)
Filename: PT_Web_TEW-755AP(V1.0R).pdf
Date: 2/27/2018
File Size: 1.51 MB
Download
Quick Installation Guide (Español)
Filename: SP_Web_TEW-755AP(V1.0R).pdf
Date: 2/27/2018
File Size: 1.50 MB
Download
Quick Installation Guide (Italiano)
Filename: ITA_Web_TEW-755AP(V1.0R).pdf
Date: 2/27/2018
File Size: 1.51 MB
Download

User's Guide

User's Guide
Filename: UG_TEW-755AP(v1).pdf
Date: 10/5/2017
File Size: 3.51 MB
Download

Product Images

JPEG Image
File Size: : 1.18 MB
Date: : 10/7/2015
Download
JPEG Image
File Size: : 838.82 KB
Date: : 10/7/2015
Download
JPEG Image
File Size: : 708.02 KB
Date: : 10/7/2015
Download
JPEG Image
File Size: : 613.72 KB
Date: : 10/7/2015
Download
JPEG Image
File Size: : 395.96 KB
Date: : 10/7/2015
Download
JPEG Image
File Size: : 932.48 KB
Date: : 10/7/2015
Download
JPEG Image
File Size: : 788.04 KB
Date: : 10/27/2015
Download
ROHS compliant WEEE crossed-out bin symbol.
Standards
  • IEEE 802.1Q
  • IEEE 802.3
  • IEEE 802.3u
  • IEEE 802.3x
  • IEEE 802.3ab
  • IEEE 802.3af
  • IEEE 802.11b
  • IEEE 802.11g
  • IEEE 802.11n (up to 300 Mbps)
Hardware Interface
  • 1 x PoE Gigabit LAN port
  • Power port (optional non-PoE installation)
  • Reset button
  • LED indicators
  • Mounting plate
Special Features
  • IP30 rated housing (with mounting plate installed)
  • WiFi traffic shaping
  • 802.1Q VLAN assignment per SSID
  • IPv6 support (Link-Local, Static IPv6, Auto-Configuration (SLAAC/DHCPv6)
  • Multi-Language interface, English, French, Spanish, German, Russian
  • LEDs on/off
  • Captive Portal (External Coovachilli server authentication)
  • Internal Captive Portal (Local user account authentication and customizable portal page)
  • 802.11k roaming assistance support
  • RSSI Scanner (Client signal strength and tolerance)
  • Airtime Fairness
Operation Modes
  • Access Point
  • Client
  • WDS AP
  • WDS Bridge
  • WDS Station
  • Repeater
Management/Monitoring
  • Web-based management
  • Software utility
  • SNMP v1/v3
  • STP
  • Event logging
  • Ping test
  • Traceroute
  • CLI
Utility OS Compatibility
  • Windows® 10, 8.1, 8, 7, Vista, XP
Access Control
  • Wireless encryption: WEP, WPA/WPA2-PSK, WPA/WPA2-RADIUS
  • MAC filter
  • Maximum client limit
QoS
  • WMM
  • Traffic shaping per SSID
SSID
  • Up to 8 SSIDs
Frequency
  • 2.4 GHz: 2.412 – 2.472 GHz
Wireless Channels
  • 2.4 GHz: FCC: 1-11, ETSI: 1 – 13
Modulation
  • DBPSK/DQPSK/CCK for DSSS technique
  • BPSK/QPSK/16-QAM/64-QAM for OFDM technique
  • 2.4 GHz: 2 x 4 dBi
Wireless Output Power/Receiving Sensitivity
  • 802.11b: FCC: 23 dBm (Max.), CE: 10 dBm (Max.) / -83 dBm (typical) @ 11 Mbps
  • 802.11g: 19 dBm (Max.), CE: 12 dBm (Max.) / -65 dBm (typical) @ 54 Mbps
  • 802.11n: FCC: 19 dBm (Max.), CE: 12 dBm (Max.) / -64 dBm (typical) @ 300 Mbps
Power
  • 12 V / 1 A consumption: 9.6 Watts Max.
Operating Temperature
  • 0 – 40 °C (32 – 104 °F)
Operating Humidity
  • Max. 95 % non-condensing
Certifications
  • CE
  • FCC
Dimensions
  • 187 x 187 x 46 mm (7.3 x 7.3 x 1.8 in.)
Weight
  • 402 g (14.2 oz.)
Warranty
  • 3 year limited

PACKAGE CONTENTS
  • TEW-755AP
  • 5 ft. (1.5 m) network cable
  • CD-ROM (Utility and User's Guide)
  • Quick Installation Guide
  • Power adapter (12 V DC, 1 A)
  • Mounting Plate

*Maximum wireless signal rates are referenced from IEEE 802.11 theoretical specifications. Actual data throughput and coverage will vary depending on interference, network traffic, building materials and other conditions. For maximum performance of up to 300 Mbps, use with a 300 Mbps 802.11n wireless adapter.

All references to speed are for comparison purposes only. Product specifications, size, and shape are subject to change without notice, and actual product appearance may differ from that depicted herein.
